Wiring Harness (sv650k5/k6) Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
HARNESS,WIRING
36610-17GF0
Superseded by 36610-17GV2
|
$688.75 | ||
|
Unavailable |
|||
|
#2
FUSE (10A)
09481-10501
|
$2.59 | ||
|
Available to order. Add to View Price |
|||
|
#3
FUSE (15A)
09481-15501
|
$2.59 | ||
|
Available to order. Add to View Price |
|||
|
#4
HOLDER, COUPLER
36687-17G10
|
$3.29 | ||
|
Unavailable |
|||
|
#5
WIRE, INJECTOR LEAD
36859-16G00
|
$189.02 | ||
|
Available to order. Add to View Price |
|||
|
#6
CLAMP (L:45)
09404-06429
|
$2.27 | ||
|
Unavailable |
|||
|
#6
CLAMP(L:80)
09404-06433
Superseded by 09404-06036
|
$2.20 | ||
|
Available to order. Add to View Price |
|||
|
#7
CLAMP
09404-08207
Superseded by 09404-08212
|
$1.64 | ||
|
Unavailable |
|||
|
#8
CLAMP (L:95)
09407-11401
|
$2.87 | ||
|
Available to order. Add to View Price |
|||
|
#8
CLAMP (L:165)
09407-18402
|
$2.77 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#9
CLAMP (L:145)
09407-14407
|
$3.83 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#10
BOLT, CLAMP
01550-06123
Superseded by 01550-0612A
|
$2.45 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#11
BOLT, NO.3
07130-06103
Superseded by 07130-0610B
|
$4.11 | ||
|
Available to order. Add to View Price |
|||
|
#12
LOCK SET
37000-16820
Superseded by 37000-16844
|
$425.43 | ||
|
Unavailable |
|||
|
#12
LOCK SET
37000-16840
Superseded by 37000-16844
|
$425.43 | ||
|
Unavailable |
|||
|
#12
LOCK SET
37000-16830
Superseded by 37000-16854
|
$451.81 | ||
|
Unavailable |
|||
|
#12
LOCK SET
37000-16850
Superseded by 37000-16854
|
$451.81 | ||
|
Unavailable |
|||
|
#13
LOCK ASSY,STEER
37100-16G20
Superseded by 37100-16G02
|
$210.23 | ||
|
Available to order. Add to View Price |
|||
|
#14
BOLT (8X20)
09139-08016
|
$4.22 | ||
|
Available to order. Add to View Price |
|||
|
#15
SWITCH ASSY, STOP LAMP
37740-45D00
|
$20.62 | ||
|
Available to order. Add to View Price |
|||
|
#16
SPRING
09443-06016
|
$3.59 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#17
SWITCH ASSY,SID
37840-16G00
Superseded by 37840-16G01
|
$99.17 | ||
|
Available to order. Add to View Price |
|||
|
#18
BOLT
01550-06257
|
$2.88 | ||
|
Available to order. Add to View Price |
|||
|
#19
HORN ASSY
38500-17G10
Superseded by 38500-17G11
|
$104.78 | ||
|
Available to order. Add to View Price |
|||
|
#20
BOLT, CLAMP
01550-06123
Superseded by 01550-0612A
|
$2.45 | ||
|
Unavailable |
|||
|
#21
RELAY ASSY, FUEL PUMP
38740-24X50
|
$58.35 | ||
|
Available to order. Add to View Price |
|||
|
#22
KEY, BLANK
37146-33E00
|
$27.38 | ||
|
Available to order. Add to View Price |
|||
