Throttle Body (model K7) Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
THROTTLE BODY
13405-17G20
|
$1,305.89 | ||
|
Unavailable |
|||
|
#1
THROTTLE BODY
13405-17G30
|
$1,061.34 | ||
|
Unavailable |
|||
|
#2
.SCREW
13269-33E00
|
$14.10 | ||
|
Available to order. Add to View Price |
|||
|
#3
.SPRING,THROTTLE SCREW
13268-48700
|
$5.36 | ||
|
Available to order. Add to View Price |
|||
|
#4
.WASHER
13606-47A00
|
$3.55 | ||
|
Available to order. Add to View Price |
|||
|
#5
.O-RING
13295-29900
Superseded by 13295-29901
|
$5.36 | ||
|
Available to order. Add to View Price |
|||
|
#6
SENSOR ASSY
13580-27G20
Superseded by 13580-27G21
|
$157.18 | ||
|
Available to order. Add to View Price |
|||
|
#7
.O-RING
13575-29G00
Superseded by 13575-29G01
|
$4.01 | ||
|
Available to order. Add to View Price |
|||
|
#8
SCREW
13605-02F00
|
$4.72 | ||
|
Available to order. Add to View Price |
|||
|
#9
ROD ASSY
13552-17G00
|
$31.69 | ||
|
Available to order. Add to View Price |
|||
|
#10
ROD ASSY
13552-16G00
|
$31.69 | ||
|
Available to order. Add to View Price |
|||
