2nd Air (model K7) Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
.VALVE ASSY,2ND AIR REED
18450-06G00
|
$38.66 | ||
|
Available to order. Add to View Price |
|||
|
#2
COVER, 2ND AIR
18531-06G01
|
$17.04 | ||
|
Available to order. Add to View Price |
|||
|
#3
BOLT
09103-06201
|
$2.97 | ||
|
Available to order. Add to View Price |
|||
|
#4
HOSE, 2ND AIR VALVE FRONT
18461-17G10
|
$24.33 | ||
|
Available to order. Add to View Price |
|||
|
#5
HOSE, 2ND AIR VALVE REAR
18471-17G00
|
$32.23 | ||
|
Available to order. Add to View Price |
|||
|
#6
CLIP (ID:15.5)
09401-15101
|
$2.75 | ||
|
Available to order. Add to View Price |
|||
|
#7
VALVE ASSY,AIR CUT
18510-27G00
Superseded by 18510-27G02
|
$98.32 | ||
|
Available to order. Add to View Price |
|||
|
#8
JOINT
13855-18A03
|
$6.99 | ||
|
Available to order. Add to View Price |
|||
|
#9
HOSE, 2ND AIR CLEANER
18711-27G00
|
$10.85 | ||
|
Available to order. Add to View Price |
|||
|
#10
.SCREW
03541-0520A
|
$2.20 | ||
|
Available to order. Add to View Price |
|||
|
#11
CLIP
09401-18304
Superseded by 09401-18304-A05
|
$2.99 | ||
|
Available to order. Add to View Price |
|||
