Frame (model K7) Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
FRAME (BLACK)
41100-17G30-YAP
Superseded by 41100-17G20-YAP
|
$3,547.11 | ||
|
Unavailable |
|||
|
#2
RAIL, SEAT (BLACK)
41200-16G40-YAP
|
$1,295.85 | ||
|
Available to order. Add to View Price |
|||
|
#3
BOLT,SEAT RAIL
41233-18G00
Superseded by 41233-18G20
|
$11.17 | ||
|
Available to order. Add to View Price |
|||
|
#4
SPACER,MOUNTING REAR UPPER RH
41941-19F01
|
$45.52 | ||
|
Available to order. Add to View Price |
|||
|
#5
SPACER, HEAD FRONT
41942-02F00
|
$32.41 | ||
|
Available to order. Add to View Price |
|||
|
#6
BOLT, SPACER
09106-08149
Superseded by 09106-08170
|
$4.47 | ||
|
Available to order. Add to View Price |
|||
|
#7
BOLT, CRANK CASE ADJUST LWR
41921-16G00
Superseded by 41921-16G01
|
$26.50 | ||
|
Unavailable |
|||
|
#8
BOLT, REAR HEAD ADJUST LH
41921-17G00
|
$39.63 | ||
|
Available to order. Add to View Price |
|||
|
#9
BOLT,CRANK CASE ADJUST CTR
41923-16G00
|
$35.31 | ||
|
Available to order. Add to View Price |
|||
|
#10
NUT, REAR HEAD ADJUST
41922-33E00
|
$25.43 | ||
|
Available to order. Add to View Price |
|||
|
#11
NUT,CRANK CASE ADJUST CTR
41922-19F00
Superseded by 41922-19F20
|
$21.34 | ||
|
Available to order. Add to View Price |
|||
