Bed Plate Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
PROTECTOR, MUFFLER
18312-HL6-A00
|
$21.42 | ||
|
Available to order. Add to View Price |
|||
|
#2
SHIELD, MUFFLER PROTECTOR
18313-HL6-A00
|
$77.89 | ||
|
Available to order. Add to View Price |
|||
|
#3
STAY, MUFFLER PROTECTOR
18314-HL6-A00
|
$86.84 | ||
|
Available to order. Add to View Price |
|||
|
#4
LOCK, BUMPER GARNISH
71509-SZA-A01
|
$2.13 | ||
|
Available to order. Add to View Price |
|||
|
#5
COVER, R. TAILLIGHT
80130-HL6-A00
|
$10.18 | ||
|
Available to order. Add to View Price |
|||
|
#6
PARTITION, FR. SNORKEL
80151-HL6-A00
|
$11.44 | ||
|
Available to order. Add to View Price |
|||
|
#7
PARTITION, RR. SNORKEL
80152-HL6-A00
|
$4.71 | ||
|
Available to order. Add to View Price |
|||
|
#8
COVER, L. TAILLIGHT
80230-HL6-A00
|
$10.18 | ||
|
Available to order. Add to View Price |
|||
|
#9
COVER, RR.
80520-HL6-AA0
|
$36.53 | ||
|
Unavailable |
|||
|
#10
PLATE ASSY., BED
81500-HL6-AF0
|
$535.35 | ||
|
Unavailable |
|||
|
#11
LID, AIR CLEANER
81511-HL6-A00
|
$53.58 | ||
|
Available to order. Add to View Price |
|||
|
#12
COVER, BED PLATE
81512-HL6-A00
|
$52.64 | ||
|
Available to order. Add to View Price |
|||
|
#13
GROMMET, SIDE COVER
83551-MA6-000
|
$4.20 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#14
HOOK ASSY., TIE DOWN
84614-S06-000
|
$14.00 | ||
|
Available to order. Add to View Price |
|||
|
#15
SCREW, SPECIAL (6X8)
90102-HN5-670
|
$1.47 | ||
|
Available to order. Add to View Price |
|||
|
#16
SCREW, SPECIAL (6X14)
90114-KWL-000
|
$2.84 | ||
|
Available to order. Add to View Price |
|||
|
#17
NUT, AIR SPOILER CLIP
90305-SH3-000
|
$8.13 | ||
|
Available to order. Add to View Price |
|||
|
#17
NUT, AIR SPOILER CLIP
90323-SE0-000
Superseded by 90305-SH3-000
|
$8.13 | ||
|
Unavailable |
|||
|
#17
NUT, AIR SPOILER CLIP
90323-SE1-000
Superseded by 90305-SH3-000
|
$8.13 | ||
|
Unavailable |
|||
|
#18
WASHER, RR. COWL SETTING
90511-MAT-000
|
$3.60 | ||
|
Available to order. Add to View Price |
|||
|
#19
CLIP, SPLASH GUARD (Honda Code 3795994)
90653-HC4-900
|
$0.67 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#20
SCREW, TAPPING (5X16)
93903-25310
|
$0.75 | ||
|
Available to order. Add to View Price |
|||
|
#21
BOLT, FLANGE (6X8)
95701-06008-08
|
$1.70 | ||
|
Unavailable |
|||
|
#22
BOLT, FLANGE (6X12)
95701-06012-07
|
$1.70 | ||
|
Available to order. Add to View Price |
|||
|
#23
BOLT, FLANGE (6X20)
95701-06020-07
|
$1.70 | ||
|
Available to order. Add to View Price |
|||
