Fuel Tank 5 Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
SCREW, TAPPING
90167-05076-00
|
$2.85 | ||
|
Available to order. Add to View Price |
|||
|
#2
RIVET
90269-06001-00
|
$6.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#3
DUCT 1
BRN-2838N-00-00
|
$61.99 | ||
|
Unavailable |
|||
|
#4
BOLT
90109-06202-00
|
$3.10 | ||
|
Available to order. Add to View Price |
|||
|
#5
NUT, SPRING
90183-05042-00
|
$1.00 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#6
MOLE 1
BRN-28345-00-00
|
$22.99 | ||
|
Unavailable |
|||
|
#7
RIVET
90269-06001-00
|
$6.49 | ||
|
Unavailable |
|||
|
#8
BOLT, BUTTON HEAD
92012-06035-00
|
$2.50 | ||
|
Available to order. Add to View Price |
|||
|
#9
COLLAR
90387-06M82-00
|
$6.25 | ||
|
Available to order. Add to View Price |
|||
|
#10
SCREW, TAPPING
90167-05076-00
|
$2.85 | ||
|
Unavailable |
|||
|
#11
RIVET
90269-06019-00
|
$3.45 | ||
|
Available to order. Add to View Price |
|||
|
#12
RIVET
90269-06001-00
|
$6.49 | ||
|
Unavailable |
|||
|
#13
DUCT 2
BRN-2838R-00-00
|
$61.99 | ||
|
Unavailable |
|||
|
#14
BOLT
90109-06202-00
|
$3.10 | ||
|
Unavailable |
|||
|
#15
NUT, SPRING
90183-05042-00
|
$1.00 | ||
|
Unavailable |
|||
|
#16
MOLE 2
BRN-28346-00-00
|
$22.99 | ||
|
Unavailable |
|||
|
#17
RIVET
90269-06001-00
|
$6.49 | ||
|
Unavailable |
|||
|
#18
BOX SUB ASSY
BRN-2830R-00-00
|
$192.99 | ||
|
Unavailable |
|||
|
#19
NUT, SPRING
90183-05042-00
|
$1.00 | ||
|
Unavailable |
|||
|
#20
SCREW, TAPPING
90167-05076-00
|
$2.85 | ||
|
Unavailable |
|||
|
#21
RIVET
90269-08006-00
|
$3.20 | ||
|
Available to order. Add to View Price |
|||
|
#22
BRACKET, CANISTOR
BRN-2419F-00-00
|
$11.49 | ||
|
Unavailable |
|||
|
#23
BOLT,WASHER BASED
90105-06206-00
|
$2.70 | ||
|
Available to order. Add to View Price |
|||
|
#24
BOLT, WITH WASHER
90119-06267-00
Superseded by 90119-06118-00
|
$9.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#25
GROMMET
90480-16013-00
|
$6.60 | ||
|
Available to order. Add to View Price |
|||
|
#26
COLLAR
90387-087K5-00
|
$11.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#27
PLATE
BRN-2413X-00-00
|
$11.99 | ||
|
Unavailable |
|||
|
#28
BOLT, HEX. SOCKET BUTTON
90111-06046-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#29
CAP
BRN-28349-00-00
|
$4.90 | ||
|
Unavailable |
|||
