Front Fork (3) Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
FORK ASSY., R. FR. (COO) (SHOWA)
51400-MGR-305
|
$891.25 | ||
|
Available to order. Add to View Price |
|||
|
#2
SPRING, FR. FORK
51401-MGR-671
|
$92.58 | ||
|
Available to order. Add to View Price |
|||
|
#3
COLLAR, SPRING (R. SIDE)
51402-ML7-921
|
$30.15 | ||
|
Available to order. Add to View Price |
|||
|
#4
PLATE, SPRING JOINT
51404-MB4-003
|
$6.20 | ||
|
Available to order. Add to View Price |
|||
|
#5
PIPE, FR. FORK
51410-MGR-671
|
$476.47 | ||
|
Available to order. Add to View Price |
|||
|
#6
RING, BACK-UP (SHOWA)
51412-MB4-003
|
$11.69 | ||
|
Available to order. Add to View Price |
|||
|
#7
BUSH, GUIDE
51414-MFJ-A51
|
$9.11 | ||
|
Available to order. Add to View Price |
|||
|
#8
BUSH, SLIDER
51415-MFJ-A51
|
$9.11 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#9
SPRING, FR. REBOUND (SHOWA)
51416-MM8-881
|
$7.40 | ||
|
Available to order. Add to View Price |
|||
|
#10
CASE, R. (LOWER)
51420-MCL-003
|
$441.27 | ||
|
Available to order. Add to View Price |
|||
|
#11
PIECE, OIL LOCK (SHOWA)
51432-MV9-003
|
$30.07 | ||
|
Available to order. Add to View Price |
|||
|
#12
RING, PISTON
51437-MB4-003
|
$11.60 | ||
|
Available to order. Add to View Price |
|||
|
#13
PIPE, SEAT
51440-MGR-671
|
$47.00 | ||
|
Available to order. Add to View Price |
|||
|
#14
RING, OIL SEAL STOPPER (SHOWA)
51447-KA4-711
|
$5.67 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#15
BOLT, FR. FORK
51455-MCL-003
|
$53.55 | ||
|
Available to order. Add to View Price |
|||
|
#16
SEAL SET, FR. FORK
51490-MER-R61
Superseded by 51490-MKA-D81
|
$27.58 | ||
|
Available to order. Add to View Price |
|||
|
#16
SEAL SET, FR. FORK
51490-MKA-D81
|
$27.58 | ||
|
Unavailable |
|||
|
#17
FORK ASSY., L. FR. (COO) (SHOWA)
51500-MGR-305
|
$852.62 | ||
|
Available to order. Add to View Price |
|||
|
#18
CASE, L. (LOWER)
51520-MCL-003
|
$441.27 | ||
|
Available to order. Add to View Price |
|||
|
#19
BOLT, SOCKET (8X35)
90109-MCR-D00
|
$3.24 | ||
|
Available to order. Add to View Price |
|||
|
#20
BOLT, SOCKET (8MM) (SHOWA)
90116-KV3-701
|
$4.89 | ||
|
Available to order. Add to View Price |
|||
|
#21
WASHER, SPECIAL (8MM) (SHOWA)
90544-283-000
|
$3.27 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#22
DUST SEAL (SHOWA)
91251-MKA-D81
|
$10.36 | ||
|
Available to order. Add to View Price |
|||
|
#22
DUST SEAL (SHOWA)
91254-MEE-D01
Superseded by 91251-MKA-D81
|
$10.36 | ||
|
Unavailable |
|||
|
#23
O-RING
91356-MB4-003
|
$4.45 | ||
|
Available to order. Add to View Price |
|||
