Cb400tiifront Brake Caliper Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#NI
PAD SET, BRAKE
06455-425-405
|
$38.45 | ||
|
Unavailable |
|||
|
#NI
PAD SET, BRAKE
451A0-425-670
Superseded by 06455-425-405
|
$38.45 | ||
|
Unavailable |
|||
|
#2
CALIPER ASSY., FR. (NOT AVAILABLE)
45100-413-871
|
$488.12 | ||
|
Available to order. Add to View Price |
|||
|
#3
CALIPER A (NOT AVAILABLE)
45101-413-003
Superseded by 45101-413-751
|
$106.06 | ||
|
Unavailable |
|||
|
#4
CALIPER B (NOT AVAILABLE)
45102-413-003
|
$135.42 | ||
|
Unavailable |
|||
|
#5
PAD (ASK) (TOKIKO)
45105-MA5-305
|
$30.27 | ||
|
Unavailable |
|||
|
#5
PAD (ASK) (TOKIKO)
45105-413-871
Superseded by 45105-MA5-305
|
$30.27 | ||
|
Unavailable |
|||
|
#5
PAD (ASK) (TOKIKO)
45105-425-003
Superseded by 45105-MA5-305
|
$30.27 | ||
|
Unavailable |
|||
|
#5
PAD (ASK) (TOKIKO)
45105-425-006
Superseded by 45105-MA5-305
|
$30.27 | ||
|
Unavailable |
|||
|
#6
PISTON
45107-413-003
|
$97.75 | ||
|
Unavailable |
|||
|
#7
SEAL, PISTON (TOKIKO)
45108-300-003
|
$14.18 | ||
|
Available to order. Add to View Price |
|||
|
#8
BOOT, PISTON
45109-413-003
|
$13.73 | ||
|
Unavailable |
|||
|
#9
CAP, BLEEDER SCREW
45110-300-003
|
$4.09 | ||
|
Available to order. Add to View Price |
|||
|
#10
CARRIER, CALIPER (NOT AVAILABLE)
45110-413-003
|
$175.74 | ||
|
Unavailable |
|||
|
#11
COVER, INDICATOR (NOT AVAILABLE)
45119-413-003
|
$3.42 | ||
|
Unavailable |
|||
|
#12
SHAFT, CALIPER (NOT AVAILABLE)
45131-413-003
|
$29.09 | ||
|
Unavailable |
|||
|
#13
BOOT, CALIPER SHAFT
45133-413-003
|
$4.47 | ||
|
Unavailable |
|||
|
#14
SHIM (NOT AVAILABLE)
45214-413-003
|
$3.91 | ||
|
Unavailable |
|||
|
#15
PIN, PAD RETAINING (NOT AVAILABLE)
45215-413-003
|
$6.04 | ||
|
Unavailable |
|||
|
#16
CLIP, PAD PIN (NOT AVAILABLE)
45223-413-003
|
$1.66 | ||
|
Unavailable |
|||
|
#17
VALVE, BLEEDER
45224-413-003
|
$8.55 | ||
|
Available to order. Add to View Price |
|||
|
#18
COVER, CALIPER
45241-413-003
|
$11.26 | ||
|
Unavailable |
|||
|
#19
O-RING (7.3X1.4)
91303-413-003
|
$2.26 | ||
|
Unavailable |
|||
|
#20
BOLT, HEX. (6X10)
92000-06010
Superseded by 92101-06010-0A
|
$1.47 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#20
BOLT, HEX. (6X10)
92101-06010-0A
|
$1.47 | ||
|
Unavailable |
|||
|
#21
SCREW-WASHER (5X10)
93892-05010-08
|
$1.20 | ||
|
Unavailable |
|||
|
#22
BOLT, FLANGE (10X32)
95800-10032-00
Superseded by 95801-10032-00
|
$2.53 | ||
|
Available to order. Add to View Price |
|||
|
#22
BOLT, FLANGE (10X32)
95801-10032-00
|
$2.53 | ||
|
Unavailable |
|||
