Headlight Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
COLLAR, AIR CLEANER MOUNTING
17239-MGS-D30
|
$4.93 | ||
|
Available to order. Add to View Price |
|||
|
#2
RUBBER, PROTECTOR GASKET
18294-KSV-J00
|
$2.24 | ||
|
Available to order. Add to View Price |
|||
|
#3
SCREW, PAN (4X55)
33103-KSC-670
|
$1.64 | ||
|
Available to order. Add to View Price |
|||
|
#4
SPRING, BEAM ADJUSTING
33107-KAE-771
|
$3.02 | ||
|
Available to order. Add to View Price |
|||
|
#5
PIPE, CP
33113-MBW-D21
|
$3.02 | ||
|
Available to order. Add to View Price |
|||
|
#6
NUT, BEAM ADJUSTING
33117-KBR-730
|
$3.67 | ||
|
Available to order. Add to View Price |
|||
|
#7
SOCKET, HEADLIGHT
33130-MKE-A41
|
$33.09 | ||
|
Available to order. Add to View Price |
|||
|
#8
HEADLIGHT UNIT (COO)
33150-KSC-A21
Superseded by 33150-KSC-305
|
$171.93 | ||
|
Available to order. Add to View Price |
|||
|
#9
BULB, HEADLIGHT (12V35/36.5W) (STANLEY)
34901-GJ1-003
|
$41.16 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#10
VISOR SET, FR. (TYPE1) (WL)
61300-MKE-AJ0ZA
|
$173.84 | ||
|
Available to order. Add to View Price |
|||
|
#11
RUBBER, LIGHT FOAM
61302-KSC-A20
|
$3.75 | ||
|
Available to order. Add to View Price |
|||
|
#12
STAY, VISOR (LOWER)
61320-MKE-A40
|
$65.22 | ||
|
Available to order. Add to View Price |
|||
|
#13
GROMMET, SIDE COVER (16MM ATTACHES PROTECTOR SET, SIDE TO COVER, PILLION STEP)
83501-MG7-000
|
$2.98 | ||
|
Available to order. Add to View Price |
|||
|
#14
BOLT-WASHER (6X20)
93404-06020-07
|
$1.70 | ||
|
Available to order. Add to View Price |
|||
|
#15
SCREW, TAPPING (5X10) (PO)
93913-25120
|
$0.77 | ||
|
Available to order. Add to View Price |
|||
