Alternator + C.d.i. Unit 81-82 Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
COVER, R. CRANKCASE
11350-KA3-700
|
$173.33 | ||
|
Unavailable |
|||
|
#2
GASKET, R.
11395-444-000
Superseded by 11395-444-306
|
$8.31 | ||
|
Unavailable |
|||
|
#4
ALTERNATOR ASSY.
31100-KA3-700
Superseded by 31100-KA3-701
|
$613.72 | ||
|
Unavailable |
|||
|
#4
ALTERNATOR ASSY.
31100-KA3-701
|
$613.72 | ||
|
Unavailable |
|||
|
#5
ROTOR (NOT AVAILABLE)
31110-KA3-700
Superseded by 31110-KA3-701
|
$330.33 | ||
|
Unavailable |
|||
|
#5
ROTOR (NOT AVAILABLE)
31110-KA3-701
|
$330.33 | ||
|
Unavailable |
|||
|
#6
STATOR (NOT AVAILABLE)
31120-KA3-700
Superseded by 31120-KA3-701
|
$355.07 | ||
|
Unavailable |
|||
|
#6
STATOR (NOT AVAILABLE)
31120-KA3-701
|
$355.07 | ||
|
Unavailable |
|||
|
#7
BOLT, REMOVING
07AMC-400A100
|
$69.23 | ||
|
Available to order. Add to View Price |
|||
|
#7
BOLT, REMOVING
89301-400-000
|
$70.62 | ||
|
Available to order. Add to View Price |
|||
|
#7
BOLT, REMOVING
89302-KA4-810
Superseded by 89301-400-000
|
$70.62 | ||
|
Unavailable |
|||
|
#8
WASHER, PLAIN (12MM)
90437-611-000
|
$5.29 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#9
NUT, FLANGE (12MM)
94050-12000
|
$1.18 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#10
BOLT, FLANGE (6X18) BOLT, HEX. (6X18)
95700-06018-00
Superseded by 95701-06018-00
|
$1.70 | ||
|
Available to order. Add to View Price |
|||
|
#10
BOLT, FLANGE (6X18)
95701-06018-00
|
$1.70 | ||
|
Unavailable |
|||
|
#11
BOLT, FLANGE (6X20)
96000-060-2000
Superseded by 96001-06020-00
|
$1.42 | ||
|
Available to order. Add to View Price |
|||
|
#11
BOLT, FLANGE (6X20)
96001-06020-00
|
$1.42 | ||
|
Unavailable |
|||
