Bumper Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
BRACKET,CARRIER 1
24W-24832-00-00
|
$61.68 | ||
|
Unavailable |
|||
|
#2
BRACKET,CARRIER 2
24W-24833-00-00
|
$39.99 | ||
|
Unavailable |
|||
|
#3
BOLT (661)
97313-08020-00
Superseded by 97013-08020-00
|
$1.80 | ||
|
Available to order. Add to View Price |
|||
|
#4
WASHER, SPRING
92990-08100-00
|
$5.60 | ||
|
Available to order. Add to View Price |
|||
|
#5
WASHER, PLATE
92901-08600-00
Superseded by 92990-08600-00
|
$2.70 | ||
|
Available to order. Add to View Price |
|||
|
#6
BUMPER, REAR 1
24W-28421-10-00
|
$53.99 | ||
|
Unavailable |
|||
|
#7
BOLT
97313-08016-00
Superseded by 97013-08016-00
|
$1.55 | ||
|
Available to order. Add to View Price |
|||
|
#8
WASHER, SPRING
92990-08100-00
|
$5.60 | ||
|
Unavailable |
|||
|
#9
WASHER, PLATE
92901-08600-00
Superseded by 92990-08600-00
|
$2.70 | ||
|
Unavailable |
|||
|
#10
BOLT (661)
97313-08020-00
Superseded by 97013-08020-00
|
$1.80 | ||
|
Unavailable |
|||
|
#11
WASHER, SPRING
92990-08100-00
|
$5.60 | ||
|
Unavailable |
|||
|
#12
WASHER, PLATE
92901-08600-00
Superseded by 92990-08600-00
|
$2.70 | ||
|
Unavailable |
|||
|
#13
SUB CARRIER ASY
24W-24830-00-00
|
$201.99 | ||
|
Unavailable |
|||
|
#14
PAD, SEAT
107-24741-00-00
|
$8.99 | ||
|
Unavailable |
|||
|
#15
DAMPER 1
24W-24855-00-00
|
$19.72 | ||
|
Unavailable |
|||
|
#16
DAMPER 2
24W-24856-00-00
|
$23.99 | ||
|
Unavailable |
|||
|
#17
BOLT
97313-08016-00
Superseded by 97013-08016-00
|
$1.55 | ||
|
Unavailable |
|||
|
#18
WASHER, SPRING
92990-08100-00
|
$5.60 | ||
|
Unavailable |
|||
|
#19
WASHER, PLATE
92901-08600-00
Superseded by 92990-08600-00
|
$2.70 | ||
|
Unavailable |
|||
|
#20
KNOB,HANDLEBAR
24W-23450-00-00
|
$29.99 | ||
|
Available to order. Add to View Price |
|||
|
#21
GROMMET
90480-10258-00
|
$2.80 | ||
|
Unavailable |
|||
|
#22
BAND
24W-2483H-00-00
|
$9.49 | ||
|
Available to order. Add to View Price |
|||
|
#23
SPACER
90560-06243-00
|
$9.49 | ||
|
Available to order. Add to View Price |
|||
|
#24
BOLT, HEX
90119-06046-00
Superseded by 97017-06035-00
|
$4.20 | ||
|
Available to order. Add to View Price |
|||
|
#25
HOOK
24W-24867-00-00
|
$69.99 | ||
|
Unavailable |
|||
|
#26
STAY, REAR
24W-24819-00-00
|
$14.49 | ||
|
Unavailable |
|||
|
#27
BOLT
97011-10020-00
Superseded by 97017-10020-00
|
$9.49 | ||
|
Available to order. Add to View Price |
|||
|
#28
WASHER, SPRING
92990-10100-00
|
$3.25 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#29
WASHER, PLATE
92990-10600-00
|
$3.00 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#30
BOLT, HEX
97313-08018-00
Superseded by 90101-08691-00
|
$4.65 | ||
|
Available to order. Add to View Price |
|||
|
#31
WASHER, SPRING
92990-08100-00
|
$5.60 | ||
|
Unavailable |
|||
|
#32
WASHER, PLATE
92901-08600-00
Superseded by 92990-08600-00
|
$2.70 | ||
|
Unavailable |
|||
|
#33
TOOL KIT (24W-28100-00)
59V-28100-00-00
|
$42.99 | ||
|
Unavailable |
|||
|
#34
TOOL BOX
1T2-21107-00-00
|
$36.99 | ||
|
Unavailable |
|||
|
#35
DAMPER,LOCATING 3
24W-24183-00-00
|
$5.49 | ||
|
Unavailable |
|||
|
#36
SCREW, WITH WASHER
90159-06060-00
|
$9.49 | ||
|
Available to order. Add to View Price |
|||
|
#37
SCREW, PAN HEAD (90501-06040-00
98580-06040-00
|
$9.49 | ||
|
Available to order. Add to View Price |
|||
|
#38
WASHER, PLATE
90201-062G3-00
Superseded by 90201-06049-00
|
$3.65 | ||
|
Available to order. Add to View Price |
|||
|
#39
NUT, U
95601-06100-00
Superseded by 95617-06100-00
|
$2.90 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
