Front Fork Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
ARM, R. SUSPENSION
51310-041-000
Superseded by 51310-041-315
|
$43.72 | ||
|
Unavailable |
|||
|
#1
ARM, R. SUSPENSION
51310-041-305
Superseded by 51310-041-315
|
$43.72 | ||
|
Unavailable |
|||
|
#1
ARM, R. SUSPENSION
51310-041-315
|
$43.72 | ||
|
Unavailable |
|||
|
#2
BUSH, FR. FORK (LOWER)
51311-041-000
Superseded by 51311-041-006
|
$8.21 | ||
|
Unavailable |
|||
|
#2
BUSH, FR. FORK (LOWER)
51311-041-006
|
$8.21 | ||
|
Unavailable |
|||
|
#3
BUSH, FR. ARM PIVOT
51312-041-000
Superseded by 51312-041-006
|
$8.38 | ||
|
Available to order. Add to View Price |
|||
|
#3
BUSH, FR. ARM PIVOT
51312-041-006
|
$8.38 | ||
|
Unavailable |
|||
|
#4
ARM, L. SUSPENSION
51320-041-000
Superseded by 51320-041-315
|
$43.72 | ||
|
Unavailable |
|||
|
#4
ARM, L. SUSPENSION
51320-041-305
Superseded by 51320-041-315
|
$43.72 | ||
|
Unavailable |
|||
|
#4
ARM, L. SUSPENSION
51320-041-315
|
$43.72 | ||
|
Unavailable |
|||
|
#5
COLLAR, FR. ARM PIVOT (NOT AVAILABLE)
51331-041-000
|
$4.42 | ||
|
Unavailable |
|||
|
#6
DUST SEAL, FR. ARM PIVOT
51332-001-000
|
$1.48 | ||
|
Unavailable |
|||
|
#7
CAP, FR. ARM PIVOT DUST SEAL
51333-001-000
|
$2.33 | ||
|
Unavailable |
|||
|
#8
COLLAR, FR. FORK DISTANCE (LOWER)
51334-041-000
|
$4.42 | ||
|
Available to order. Add to View Price |
|||
|
#9
DUST SEAL, FR. FORK (LOWER)
51335-001-000
|
$2.42 | ||
|
Available to order. Add to View Price |
|||
|
#10
CAP, FR. FORK DUST SEAL (LOWER)
51336-001-000
|
$2.51 | ||
|
Available to order. Add to View Price |
|||
|
#11
STOPPER, FR. ARM
51351-041-010
|
$3.87 | ||
|
Available to order. Add to View Price |
|||
|
#12
FORK ASSY., FR. (NOT AVAILABLE)
51400-041-010
|
$80.32 | ||
|
Unavailable |
|||
|
#13
SPRING, FR. FORK (NOT AVAILABLE)
51401-041-010
|
$15.98 | ||
|
Unavailable |
|||
|
#14
SEAT, FR. FORK SPRING
51407-001-000
|
$1.77 | ||
|
Unavailable |
|||
|
#15
GUIDE, FR. FORK SPRING (NOT AVAILABLE)
51409-001-020
|
$1.24 | ||
|
Unavailable |
|||
|
#16
METAL, FR. FORK (LOWER)
51420-041-010
|
$96.57 | ||
|
Unavailable |
|||
|
#17
RUBBER, FR. FORK STOPPER (NOT AVAILABLE)
51475-041-000
|
$2.50 | ||
|
Unavailable |
|||
|
#18
NUT, FR. FORK LOCK
51482-041-000
|
$2.39 | ||
|
Available to order. Add to View Price |
|||
|
#19
COLLAR, FR. FORK (OUTER)
51486-041-050
|
$1.77 | ||
|
Unavailable |
|||
|
#20
WASHER, FR. FORK JOINT (NOT AVAILABLE)
51487-041-000
|
$2.05 | ||
|
Unavailable |
|||
|
#21
RUBBER A, FR. FORK JOINT (NOT AVAILABLE)
51488-041-010
|
$1.31 | ||
|
Unavailable |
|||
|
#22
RUBBER B, FORK
51489-041-000
|
$1.19 | ||
|
Unavailable |
|||
|
#23
COLLAR, FR. FORK (LOWER)
51491-041-010
|
$1.90 | ||
|
Available to order. Add to View Price |
|||
|
#24
BOLT, FR. ARM PIVOT
90125-041-000
|
$5.04 | ||
|
Available to order. Add to View Price |
|||
|
#25
BOLT, FR. FORK (LOWER)
90149-041-010
|
$2.22 | ||
|
Available to order. Add to View Price |
|||
|
#26
NUT, LOCK (7MM)
90308-041-000
|
$2.31 | ||
|
Unavailable |
|||
|
#27
BOLT, HEX. (8X50) (SOURCE: VINTAGE PARTS INC.)
93200-08050-0A
|
$1.09 | ||
|
Unavailable |
|||
|
#28
NUT, HEX. (8MM)
94001-08000-0S
|
$1.37 | ||
|
Available to order. Add to View Price |
|||
|
#29
NUT, HEX. (8MM)
94002-08000-0S
|
$1.37 | ||
|
Available to order. Add to View Price |
|||
|
#30
WASHER, SPRING (8MM)
94111-08000
|
$1.03 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#31
PIN, LOCK (6MM)
94251-06000
|
$1.08 | ||
|
Available to order. Add to View Price |
|||
|
#32
FITTING, GREASE (A.45)
96201-30000
Superseded by 96201-30001
|
$1.28 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#32
FITTING, GREASE (A.45)
96201-30001
|
$1.28 | ||
|
Unavailable |
|||
