Propeller Shaft/final Drive Gear (model K8/k9) Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
YOKE, UNIVERSAL JOINT
27100-48G00
Superseded by 27100-48G20
|
$390.59 | ||
|
Available to order. Add to View Price |
|||
|
#1
YOKE, UNIVERSAL JOINT
27100-48G20
|
$390.59 | ||
|
Unavailable |
|||
|
#2
SHAFT, PROPELLER
27151-48G10
Superseded by 27151-48G20
|
$309.48 | ||
|
Available to order. Add to View Price |
|||
|
#3
SEAL, COUPLING OIL
09283-30026
|
$13.23 | ||
|
Available to order. Add to View Price |
|||
|
#4
CIRCLIP, COUPLING
09381-40003
|
$5.85 | ||
|
Available to order. Add to View Price |
|||
|
#5
SPRING, PROPELLER SHAFT
09440-30008
|
$4.05 | ||
|
Available to order. Add to View Price |
|||
|
#6
GEAR & CASE SET
27300-48820
Superseded by 27300-48851-13L
|
$2,156.34 | ||
|
Available to order. Add to View Price |
|||
|
#7
COUPLING, FINAL DRIVE GEAR
27172-24A00
|
$67.50 | ||
|
Available to order. Add to View Price |
|||
|
#8
GEAR, FINAL DRIVE BEVEL
27311-24A03
|
$217.41 | ||
|
Unavailable |
|||
|
#9
STOPPER, FINAL DRIVE BE
27312-24A02
|
$83.62 | ||
|
Available to order. Add to View Price |
|||
|
#10
PLATE, BEARING STOPPER
27313-38B00
|
$8.32 | ||
|
Available to order. Add to View Price |
|||
|
#11
PLATE, BEARING STOPPER
27313-38B10
|
$8.32 | ||
|
Available to order. Add to View Price |
|||
|
#12
.SHIM SET,FINAL DRIVE GEAR (T
27445-24810
|
$31.82 | ||
|
Available to order. Add to View Price |
|||
|
#13
BOLT, FINAL GEAR CASE STUD
09108-10106
|
$5.10 | ||
|
Available to order. Add to View Price |
|||
|
#14
NUT, FINAL GEAR CASE
09159-10026
|
$7.93 | ||
|
Available to order. Add to View Price |
|||
|
#15
NUT, FINAL DRIVE GEAR
09159-16003
|
$4.35 | ||
|
Available to order. Add to View Price |
|||
|
#16
WASHER, FINAL DRIVE NUT
09160-16029
|
$6.92 | ||
|
Available to order. Add to View Price |
|||
|
#17
.WASHER (54X68X1.5)
09160-54001
|
$9.50 | ||
|
Available to order. Add to View Price |
|||
|
#18
WASHER, FINAL GEAR CASE NUT
09164-10008
|
$2.18 | ||
|
Available to order. Add to View Price |
|||
|
#19
BEARING, FINAL DRIVE GEAR
09262-28023
|
$138.97 | ||
|
Available to order. Add to View Price |
|||
|
#20
.BEARING (20X34X18)
09263-20062
|
$51.07 | ||
|
Available to order. Add to View Price |
|||
|
#21
O RING (D:3.1,ID:63.9)
09280-64003
|
$7.08 | ||
|
Available to order. Add to View Price |
|||
|
#22
.OIL SEAL (45.5X58X7)
09283-47002
|
$18.69 | ||
|
Available to order. Add to View Price |
|||
|
#23
.GEAR,FINAL DRIVEN BEVEL (NT:
27320-48G00
|
$544.12 | ||
|
Available to order. Add to View Price |
|||
|
#24
.SHIM SET,FINAL DRIVEN GEAR R
27326-48811
|
$116.29 | ||
|
Available to order. Add to View Price |
|||
|
#25
SHIM SET, FINAL DRIVE, R
27327-38810
|
$122.40 | ||
|
Available to order. Add to View Price |
|||
|
#26
.BEARING (85X130X14)
09262-85001
|
$219.83 | ||
|
Available to order. Add to View Price |
|||
|
#27
.BEARING (40X50X20)
09263-40016
|
$74.96 | ||
|
Available to order. Add to View Price |
|||
|
#28
.OIL SEAL (38X46X6)
09283-38026
|
$20.89 | ||
|
Available to order. Add to View Price |
|||
|
#29
.OIL SEAL (85X110X11)
09289-85001
|
$53.46 | ||
|
Available to order. Add to View Price |
|||
|
#30
CASE, FINAL GEAR (SILVER)
27450-48G10
Superseded by 27450-48G70-13L
|
$1,033.69 | ||
|
Available to order. Add to View Price |
|||
|
#31
.CASE,FINAL GEAR BEARING
27461-38B00
|
$267.00 | ||
|
Available to order. Add to View Price |
|||
|
#32
.GASKET (13.8X18.8X4.8)
09168-14002
|
$2.83 | ||
|
Unavailable |
|||
|
#33
PLUG (MAGNETO)
09247-14002
|
$6.57 | ||
|
Available to order. Add to View Price |
|||
|
#34
PLUG, FINAL GEAR CASE
09248-16012
|
$5.83 | ||
|
Available to order. Add to View Price |
|||
|
#35
.PLUG (30X9)
09259-30007
|
$23.52 | ||
|
Available to order. Add to View Price |
|||
|
#36
O-RING (D:3.1,ID:26.4)
09280-26006
|
$3.46 | ||
|
Available to order. Add to View Price |
|||
|
#37
.BOLT
01550-0825A
|
$2.88 | ||
|
Available to order. Add to View Price |
|||
|
#38
BOLT
01550-1025A
|
$3.91 | ||
|
Available to order. Add to View Price |
|||
