Shelter Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
RUBBER, AIR CLEANER MOUNTING
17227-GS3-000
|
$3.82 | ||
|
Available to order. Add to View Price |
|||
|
#2
RUBBER, FR. FENDER MOUNTING (Honda Code 0329987)
61103-357-000
|
$4.11 | ||
|
Available to order. Add to View Price |
|||
|
#3
COLLAR, FR. FENDER (WHITE)
61104-357-000
Superseded by 61104-428-010
|
$5.29 | ||
|
Available to order. Add to View Price |
|||
|
#3
COLLAR, FR. FENDER (WHITE)
61104-428-000
Superseded by 61104-428-010
|
$5.29 | ||
|
Unavailable |
|||
|
#3
COLLAR, FR. FENDER (WHITE) (FOR RR.)
61104-428-010
|
$5.29 | ||
|
Unavailable |
|||
|
#4
SPRING, LOCK KEY SETTING
75581-673-000
|
$6.45 | ||
|
Available to order. Add to View Price |
|||
|
#5
LOCK ASSY., FUEL LID
77232-GBL-772
|
$19.77 | ||
|
Available to order. Add to View Price |
|||
|
#6
LID, SHELTER *R114CU* (CANDY WINE BERRY RED-U)
83131-MT3-000ZQ
|
$52.21 | ||
|
Unavailable |
|||
|
#7
RUBBER, SHELTER LID
83132-MN5-000
|
$2.73 | ||
|
Available to order. Add to View Price |
|||
|
#8
HINGE, SHELTER
83140-MT3-000
|
$28.22 | ||
|
Unavailable |
|||
|
#9
PLATE, LOCK
83143-MT3-000
|
$7.08 | ||
|
Unavailable |
|||
|
#11
GROMMET, SIDE COVER
83551-MA6-000
|
$4.20 | ||
|
Available to order. Add to View Price |
|||
|
#12
SCREW, TAPPING (4X12) (PO)
90101-SA4-000
Superseded by 93913-14280
|
$0.95 | ||
|
Available to order. Add to View Price |
|||
|
#12
SCREW, TAPPING (4X12) (PO) SCREW, PAN (4X8)
93913-14280
|
$0.95 | ||
|
Unavailable |
|||
|
#13
SCREW, SPECIAL (6X19)
90104-MN4-000
|
$7.27 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#14
BOLT, FLANGE (6X25)
95701-06025-00
|
$1.88 | ||
|
Available to order. Add to View Price |
|||
|
#15
MAT A, SHELTER
83151-MAJ-G00
|
$11.47 | ||
|
Unavailable |
|||
|
#16
MAT B, R. SHELTER
83152-MAJ-G00
|
$10.89 | ||
|
Available to order. Add to View Price |
|||
|
#17
MAT B, L. SHELTER
83153-MAJ-G00
|
$10.89 | ||
|
Available to order. Add to View Price |
|||
|
#18
SHELTER ASSY., TOP (TYPE13) (WL)
83160-MAJ-G70ZA
|
$606.51 | ||
|
Unavailable |
|||
