2018 Yamaha YZ 250 X Governor OEM Parts

Governor Diagram

Item MSRP Qty
#1 PLATE, THRUST 1
4JY-11915-10-00
$8.49
Available to order.
Add to View Price
#2 SCREW,BINDING
98902-05012-00
Superseded by 98904-05012-00
$1.85
Available to order.
Add to View Price
#3 BOLT, FLANGE
90105-05014-00
$2.95
Available to order.
Add to View Price
#4 WASHER, PLATE
90201-05021-00
$2.10
Available to order.
Add to View Price
#5 COLLAR
90387-085E1-00
$8.49
Available to order.
Add to View Price
#6 OIL SEAL
93104-08040-00
$16.49
In Stock: Ready to ship.
Add to View Price
#7 PUSH ROD ASSY
5CU-11990-10-00
$183.99
Available to order.
Add to View Price
#8 FORK, GOVERNOR
3JE-11922-01-00
$47.99
Available to order.
Add to View Price
#9 BOLT, HEXAGON SOCKET HEAD
91312-04006-00
$3.20
In Stock: Ready to ship.
Add to View Price
#10 BEARING
93300-60801-00
Superseded by 93300-60814-00
$23.99
Available to order.
Add to View Price
#11 BEARING
93300-60801-00
Superseded by 93300-60814-00
$23.99
Unavailable
#12 SHAFT, GOVERNOR
5X4-11921-02-00
$61.99
Available to order.
Add to View Price
#13 GEAR, GOVERNOR
5NY-11953-00-00
$62.99
Available to order.
Add to View Price
#14 SPRING, COMPRESSION
90501-290A2-00
$18.49
Available to order.
Add to View Price
#15 PLATE
5CU-11952-00-00
$18.99
Available to order.
Add to View Price
#16 WASHER, PLATE (T=0.8)
90201-154F5-00
$11.49
Available to order.
Add to View Price
#17 COLLAR
90387-152F2-00
$16.49
Available to order.
Add to View Price
#18 BEARING
93340-21505-00
$20.99
Available to order.
Add to View Price
#19 RETAINER, WEIGHT
5CU-11912-00-00
$65.99
Available to order.
Add to View Price
#20 RETAINER
5CU-11911-00-00
$129.99
Available to order.
Add to View Price
#21 BALL
93507-16020-00
$2.60
Available to order.
Add to View Price
#22 PIN, DOWEL
93603-14240-00
$2.30
Available to order.
Add to View Price
#23 PIN, DOWEL
93604-29184-00
$3.50
In Stock: Ready to ship.
Add to View Price
