Starter Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
GEAR, KICK IDLE
1LX-15651-00-00
|
$60.99 | ||
|
Unavailable |
|||
|
#2
SHIM 1 (0.5T)
137-17417-00-05
|
$5.49 | ||
|
Available to order. Add to View Price |
|||
|
#3
CIRCLIP
93440-15012-00
|
$9.49 | ||
|
Available to order. Add to View Price |
|||
|
#4
KICK AXLE ASSY
1LX-15660-02-00
Superseded by 1LX-15660-03-00
|
$156.99 | ||
|
Available to order. Add to View Price |
|||
|
#5
GEAR, KICK
1LX-15641-00-00
|
$57.99 | ||
|
Available to order. Add to View Price |
|||
|
#6
CLIP
90468-26048-00
|
$9.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#7
SPRING, TORSION
90508-26450-00
|
$12.49 | ||
|
Available to order. Add to View Price |
|||
|
#8
WASHER, PLATE
90201-171G4-00
|
$10.49 | ||
|
Available to order. Add to View Price |
|||
|
#9
SPACER
90560-17279-00
|
$17.49 | ||
|
Available to order. Add to View Price |
|||
|
#10
OIL SEAL
93102-17263-00
|
$11.49 | ||
|
Available to order. Add to View Price |
|||
|
#11
KICK CRANK ASSY
4DB-15620-03-00
Superseded by 4DB-15620-10-00
|
$235.99 | ||
|
Available to order. Add to View Price |
|||
|
#12
BOSS, KICK CRANK
4DB-15621-03-00
|
$73.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
SPRING, COMPRESSION
90501-12081-00
|
$9.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#14
BALL
93507-32031-00
|
$5.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#15
O-RING
93210-15171-00
|
$8.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#16
SCREW, COUNTERSUNK
90152-06010-00
|
$10.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#17
BOLT
97021-06012-00
Superseded by 97017-06012-00
|
$4.05 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#18
WASHER, PLATE
90201-065F3-00
Superseded by 90201-06020-00
|
$10.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
