2014 Yamaha YZF R6 COWLING 1 OEM Parts Diagram

< Back to Assembly Types

Item	MSRP	Qty
#1 WINDSHIELD 13S-28381-10-00	$64.99
Available: Ships in 7-12 days. Add to View Price
#2 SCREW, ROUND HEAD 90150-05023-00	$6.49
In Stock: Ready to ship. Add to View Price
#3 NUT 90179-05523-00	$6.49
In Stock: Ready to ship. Add to View Price
#4 PANEL, INNER 1 13S-2836K-00-00	$67.99
In Stock: Ready to ship. Add to View Price
#5 DAMPER 1 3P6-28217-00-00	$6.49
In Stock: Ready to ship. Add to View Price
#6 DAMPER 2 13S-28227-00-00	$6.49
In Stock: Ready to ship. Add to View Price
#7 DAMPER 3 13S-28237-00-00	$6.49
In Stock: Ready to ship. Add to View Price
#8 DAMPER 13S-28371-00-00	$6.49
Available: Ships in 7-12 days. Add to View Price
#9 RIVET 90269-06046-00 Superseded by 90269-06001-00	$4.90
In Stock: Ready to ship. Add to View Price
#10 COVER 13S-28365-10-00	$12.99
In Stock: Ready to ship. Add to View Price
#11 SCREW, TAPPING 97702-40016-00 Superseded by 97707-40016-00	$6.49
Available: Ships in 7-12 days. Add to View Price
#12 BODY, FRONT UPPER 1 13S-2835G-00-P1	$251.99
Available: Ships in 7-12 days. Add to View Price
#12 BODY, FRONT UPPER 1 13S-2835G-00-P6	$213.99
Available: Ships in 7-12 days. Add to View Price
#12 BODY, FRONT UPPER 1 13S-2835G-00-P9	$213.99
Available: Ships in 7-12 days. Add to View Price
#13 NUT, SPRING 90183-05076-00 Superseded by 90183-050A6-00	$6.49
In Stock: Ready to ship. Add to View Price
#14 NUT, SPRING 90183-05042-00	$6.49
In Stock: Ready to ship. Add to View Price
#15 DAMPER, 4 2C0-28455-00-00	$6.49
Available: Ships in 7-12 days. Add to View Price
#16 GROMMET 90480-01605-00	$6.49
Available: Ships in 7-12 days. Add to View Price
#17 BODY, FRONT UPPER 2 13S-2835H-00-P1	$269.99
Available: Ships in 7-12 days. Add to View Price
#17 BODY, FRONT UPPER 2 13S-2835H-00-P6	$242.99
In Stock: Ready to ship. Add to View Price
#17 BODY, FRONT UPPER 2 13S-2835H-00-P9	$242.99
Available: Ships in 7-12 days. Add to View Price
#18 NUT, SPRING 90183-05076-00 Superseded by 90183-050A6-00	$6.49
Unavailable
#19 NUT, SPRING 90183-05042-00	$6.49
Unavailable
#20 DAMPER, 4 2C0-28455-00-00	$6.49
Unavailable
#21 GROMMET 90480-01605-00	$6.49
Unavailable
#22 SCREW, TRUSS HEAD TAPPING 97707-50016-00	$3.30
In Stock: Ready to ship. Add to View Price
#23 SCREW, TAPPING 97707-40012-00	$6.49
Available: Ships in 7-12 days. Add to View Price
#24 STAY 1 13S-28356-00-00	$364.99
In Stock: Ready to ship. Add to View Price
#25 DAMPER 4XV-83513-00-00	$6.49
In Stock: Ready to ship. Add to View Price
#26 BOLT, HEX. SOCKET BUTTON 90111-06116-00	$6.49
In Stock: Ready to ship. Add to View Price
#27 JOINT 2C0-28342-01-00	$6.49
Available: Ships in 7-12 days. Add to View Price
#28 DAMPER 1 2C0-28217-00-00	$2.20
Available: Ships in 7-12 days. Add to View Price
#29 DAMPER 2 2C0-28227-00-00	$6.49
Available: Ships in 7-12 days. Add to View Price
#30 DUCT 2 13S-2838R-00-00	$10.99
Available: Ships in 7-12 days. Add to View Price
#31 DUCT 3 13S-2838T-00-00	$10.99
Available: Ships in 7-12 days. Add to View Price
#32 SCREW, TAPPING 97702-40016-00 Superseded by 97707-40016-00	$6.49
Unavailable
#33 SENSOR, AIR TEMPERATURE 8FP-85886-00-00	$41.99
Available: Ships in 7-12 days. Add to View Price
#34 SCREW, TAPPING 97702-50116-00 Superseded by 97780-50116-00	$2.99
Available: Ships in 7-12 days. Add to View Price
#35 DAMPER 2 51Y-21639-00-00	$6.49
Available: Ships in 7-12 days. Add to View Price
#36 DAMPER 2C0-28371-00-00	$24.99
Available: Ships in 7-12 days. Add to View Price
#37 RIVET 90269-06008-00	$6.49
In Stock: Ready to ship. Add to View Price
#38 RIVET 90269-06008-00	$6.49
Unavailable
#39 PANEL, CONSOLE 1 13S-2837L-00-00	$16.49
Available: Ships in 7-12 days. Add to View Price
#40 BOLT, HEX. SOCKET BUTTON 90111-05021-00	$6.49
Available: Ships in 7-12 days. Add to View Price
#41 PANEL, CONSOLE 2 13S-2837M-00-00	$16.49
Available: Ships in 7-12 days. Add to View Price
#42 BOLT, HEX. SOCKET BUTTON 90111-05021-00	$6.49
Unavailable
#43 PLATE, MIRROR FITTING 1 13S-26298-00-00	$8.49
In Stock: Ready to ship. Add to View Price
#44 REAR VIEW MIRROR ASSY (LEFT) 13S-26280-10-00	$101.99
Available: Ships in 7-12 days. Add to View Price
#45 COLLAR 90387-064T3-00	$6.49
In Stock: Ready to ship. Add to View Price
#46 NUT, CROWN 90176-06008-00	$6.49
In Stock: Ready to ship. Add to View Price
#47 REAR VIEW MIRROR ASSY (RIGHT) 13S-26290-10-00	$96.99
Available: Ships in 7-12 days. Add to View Price
#48 COLLAR 90387-064T3-00	$6.49
Unavailable
#49 NUT, CROWN 90176-06008-00	$6.49
Unavailable
#50 COVER 7 13S-2117V-00-P1	$190.99
Available: Ships in 7-12 days. Add to View Price
#50 COVER 7 13S-2117V-00-P6	$209.99
Available: Ships in 7-12 days. Add to View Price
#50 COVER 7 13S-2117V-00-P9	$192.99
Available: Ships in 7-12 days. Add to View Price
#51 GROMMET 90480-12613-00	$18.49
Available: Ships in 7-12 days. Add to View Price
#52 COLLAR 90387-067K8-00	$5.49
In Stock: Ready to ship. Add to View Price
#53 GROMMET 90480-14003-00	$6.49
In Stock: Ready to ship. Add to View Price
#54 COLLAR 90387-06260-00	$6.49
In Stock: Ready to ship. Add to View Price
#55 NUT, SPRING 90183-05076-00 Superseded by 90183-050A6-00	$6.49
Unavailable
#56 PLUG 90338-06134-00	$4.90
Available: Ships in 7-12 days. Add to View Price
#57 BOLT,HEX. SOCKET BUT 90110-05201-00 Superseded by 90111-05059-00	$0.65
Available: Ships in 7-12 days. Add to View Price
#58 WASHER, PLATE 90202-05180-00	$6.49
In Stock: Ready to ship. Add to View Price
#59 BOLT, HEX. SOCKET BUTTON 90111-06063-00	$6.49
Available: Ships in 7-12 days. Add to View Price
#60 BOLT, HEX. SOCKET BUTTON 90111-06040-00	$3.30
In Stock: Ready to ship. Add to View Price
#61 COVER 8 13S-2117W-00-P1	$181.99
Available: Ships in 7-12 days. Add to View Price
#61 COVER 8 13S-2117W-00-P6	$209.99
Available: Ships in 7-12 days. Add to View Price
#61 COVER 8 13S-2117W-00-P9	$200.99
Available: Ships in 7-12 days. Add to View Price
#62 GROMMET 90480-12613-00	$18.49
Unavailable
#63 COLLAR 90387-067K8-00	$5.49
Unavailable
#64 GROMMET 90480-14003-00	$6.49
Unavailable
#65 COLLAR 90387-06260-00	$6.49
Unavailable
#66 NUT, SPRING 90183-05076-00 Superseded by 90183-050A6-00	$6.49
Unavailable
#67 PLUG 90338-06134-00	$4.90
Unavailable
#68 CLAMP 90464-20014-00	$3.30
Available: Ships in 7-12 days. Add to View Price
#69 BOLT,HEX. SOCKET BUT 90110-05201-00 Superseded by 90111-05059-00	$0.65
Unavailable
#70 WASHER, PLATE 90202-05180-00	$6.49
Unavailable
#71 BOLT, HEX. SOCKET BUTTON 90111-06063-00	$6.49
Unavailable
#72 BOLT, HEX. SOCKET BUTTON 90111-06040-00	$3.30
Unavailable
#73 LABEL, NOTICE WINDSHIELD 1 4B5-2815K-00-00	$2.99
Available: Ships in 7-12 days. Add to View Price
#74 GRAPHIC, 12 2CX-2832K-10-00	$32.99
In Stock: Ready to ship. Add to View Price
#74 GRAPHIC, 12 2CX-2832K-20-00	$32.99
In Stock: Ready to ship. Add to View Price
#75 GRAPHIC, 13 2CX-2832L-10-00	$32.99
Available: Ships in 7-12 days. Add to View Price
#75 GRAPHIC, 13 2CX-2832L-20-00	$32.99
Available: Ships in 7-12 days. Add to View Price
