Rear Wheel Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
CAST WHEEL, REAR
3P6-25338-01-98
|
$775.99 | ||
|
Available to order. Add to View Price |
|||
|
#2
BEARING
93306-30446-00
|
$72.99 | ||
|
Available to order. Add to View Price |
|||
|
#3
NUT, ADJUSTING
1MC-2538E-00-00
|
$44.99 | ||
|
Available to order. Add to View Price |
|||
|
#4
OIL SEAL
93106-40013-00
|
$16.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#5
SPACER, BEARING
3P6-25317-00-00
|
$44.99 | ||
|
Available to order. Add to View Price |
|||
|
#6
BEARING
93317-42592-00
|
$53.99 | ||
|
Available to order. Add to View Price |
|||
|
#7
COLLAR, WHEEL
5JW-25383-00-00
|
$44.99 | ||
|
Available to order. Add to View Price |
|||
|
#8
CLUTCH, HUB
5JW-25366-00-00
|
$200.99 | ||
|
Available to order. Add to View Price |
|||
|
#9
BEARING
93306-20480-00
|
$48.99 | ||
|
Available to order. Add to View Price |
|||
|
#10
DAMPER
5JW-25364-00-00
|
$31.99 | ||
|
Available to order. Add to View Price |
|||
|
#11
SEAL, HUB DUST
5JW-25319-00-00
|
$41.99 | ||
|
Available to order. Add to View Price |
|||
|
#12
COVER, PLATE
5JW-25327-00-00
|
$79.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
SCREW
90149-05030-00
|
$2.80 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#14
ROTOR, SENSOR
3P6-2517G-00-00
|
$49.99 | ||
|
Available to order. Add to View Price |
|||
|
#15
SCREW
90149-05029-00
Superseded by 90149-05030-00
|
$2.80 | ||
|
Unavailable |
|||
|
#16
TIRE
94118-17074-00
Superseded by 94118-17086-00
|
$523.99 | ||
|
Available to order. Add to View Price |
|||
|
#17
VALVE, RIM (TR412)
93900-00030-00
|
$18.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#18
BALANCER, WHEEL (10G)
5MT-25398-00-00
|
$18.99 | ||
|
Available to order. Add to View Price |
|||
|
#18
BALANCER, WHEEL (20G)
5MT-25398-10-00
|
$18.99 | ||
|
Available to order. Add to View Price |
|||
|
#18
BALANCER, WHEEL (30G)
5MT-25398-20-00
|
$46.99 | ||
|
Available to order. Add to View Price |
|||
|
#19
AXLE, WHEEL
5JW-25381-10-00
|
$92.99 | ||
|
Available to order. Add to View Price |
|||
|
#20
WASHER, PLATE
90201-181U5-00
|
$25.99 | ||
|
Available to order. Add to View Price |
|||
|
#21
NUT, SELF-LOCKING
90185-18009-00
|
$20.99 | ||
|
Available to order. Add to View Price |
|||
|
#22
WASHER
92902-20600-00
Superseded by 92903-20600-00
|
$9.49 | ||
|
Available to order. Add to View Price |
|||
|
#23
BAR, TENSION
5JW-25371-10-00
|
$48.99 | ||
|
Available to order. Add to View Price |
|||
|
#24
BOLT, HEXAGON SOCKET HEAD
90110-08106-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#25
NUT, SELF-LOCKING
95602-08200-00
|
$3.20 | ||
|
Available to order. Add to View Price |
|||
|
#26
CLAMP
90464-23239-00
|
$2.80 | ||
|
Available to order. Add to View Price |
|||
|
#27
HOUSING, SENSOR REAR
1MC-2537A-00-00
|
$139.99 | ||
|
Available to order. Add to View Price |
|||
|
#28
COLLAR, WHEEL
1MC-25383-00-00
|
$31.99 | ||
|
Available to order. Add to View Price |
|||
