Taillight 79-82 Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
WASHER, CHAIN CASE SETTING
90522-028-000
|
$3.29 | ||
|
Available to order. Add to View Price |
|||
|
#2
SUB-WIRE, TAILLIGHT
32101-KY0-980
|
$20.57 | ||
|
Unavailable |
|||
|
#2
SUB-WIRE, TAILLIGHT
32200-428-000
Superseded by 32101-KY0-980
|
$20.57 | ||
|
Unavailable |
|||
|
#3
TAILLIGHT ASSY. (NOT AVAILABLE)
33700-428-672
Superseded by 33700-428-673
|
$130.28 | ||
|
Unavailable |
|||
|
#3
TAILLIGHT ASSY. (NOT AVAILABLE)
33700-428-673
|
$130.28 | ||
|
Unavailable |
|||
|
#4
LENS, TAILLIGHT
33702-329-671
|
$21.99 | ||
|
Unavailable |
|||
|
#5
SOCKET, TAILLIGHT (NOT AVAILABLE)
33703-428-672
Superseded by 33703-428-673
|
$124.79 | ||
|
Unavailable |
|||
|
#5
SOCKET, TAILLIGHT (NOT AVAILABLE)
33703-428-673
|
$124.79 | ||
|
Unavailable |
|||
|
#6
WIRE, TAILLIGHT (STANLEY)
33705-147-671
|
$10.97 | ||
|
Unavailable |
|||
|
#7
GASKET, TAILLIGHT LENS
33709-092-671
|
$4.15 | ||
|
Available to order. Add to View Price |
|||
|
#8
SEAT, RUBBER BASE
33712-428-610
Superseded by 33712-428-003
|
$11.17 | ||
|
Unavailable |
|||
|
#9
COLLAR, TAILLIGHT (NOT AVAILABLE)
33713-428-610
|
$2.06 | ||
|
Unavailable |
|||
|
#10
COLLAR, TAILLIGHT
33713-437-000
|
$3.78 | ||
|
Unavailable |
|||
|
#11
BULB, STOP & TAILLIGHT (6V32/3CP) (STANLEY)
34906-329-671
|
$8.15 | ||
|
Available to order. Add to View Price |
|||
|
#12
SCREW, TAPPING (4X75)
90147-428-003
|
$2.39 | ||
|
Available to order. Add to View Price |
|||
|
#13
NUT, FLANGE (6MM)
94050-06080
|
$0.68 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#14
BOLT, FLANGE (6X22)
95700-06022-00
Superseded by 95701-06022-00
|
$1.88 | ||
|
Available to order. Add to View Price |
|||
|
#14
BOLT, FLANGE (6X22)
95701-06022-00
|
$1.88 | ||
|
Unavailable |
|||
