Starter Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
KICK AXLE ASSY
5PA-15660-00-00
|
$112.99 | ||
|
Available to order. Add to View Price |
|||
|
#2
GEAR, KICK
5PA-15641-00-00
|
$84.99 | ||
|
Available to order. Add to View Price |
|||
|
#3
CLIP
90468-23194-00
|
$10.49 | ||
|
Available to order. Add to View Price |
|||
|
#4
WASHER, PLATE
90201-176L4-00
|
$10.49 | ||
|
Available to order. Add to View Price |
|||
|
#5
SPRING, TORSION
90508-26750-00
|
$13.49 | ||
|
Available to order. Add to View Price |
|||
|
#6
GUIDE, SPRING
4ES-15664-00-00
|
$33.99 | ||
|
Available to order. Add to View Price |
|||
|
#7
OIL SEAL
93102-17263-00
|
$11.49 | ||
|
Available to order. Add to View Price |
|||
|
#8
GEAR, KICK IDLE
5PA-15651-00-00
|
$79.99 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#9
WASHER, PLATE
90201-124F8-00
|
$10.49 | ||
|
Available to order. Add to View Price |
|||
|
#10
CIRCLIP
99009-12400-00
|
$3.59 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#11
KICK CRANK ASSY
BR8-15620-00-00
|
$142.99 | ||
|
Available to order. Add to View Price |
|||
|
#12
BOSS, KICK CRANK
BR8-15621-00-00
|
$62.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
SPRING, BOSS STOPPER
90501-12081-00
|
$9.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#14
BALL
93507-32009-00
Superseded by 93507-32031-00
|
$5.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#15
O-RING
93210-12152-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#16
PLUG, TAPER
90336-06031-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#17
PIN, DOWEL
93603-16219-00
|
$9.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#18
PLATE, THRUST 1
4JY-11915-10-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#19
BOLT, HEX. SOCKET BUTTON
90111-05052-00
Superseded by 90111-05053-00
|
$1.45 | ||
|
Available to order. Add to View Price |
|||
|
#20
BOLT, FLANGE DEEP RECESS
95E32-06012-00
|
$1.10 | ||
|
Available to order. Add to View Price |
|||
|
#21
WASHER, PLATE
90201-06060-00
Superseded by 90201-06020-00
|
$10.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
