Exhaust Yz400c Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
JET, MAIN #160
137-14143-34-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#
PIPE, EXHAUST L
510-14611-01-00
|
$88.99 | ||
|
Unavailable |
|||
|
#
PLATE
510-14477-20-00
|
$1.98 | ||
|
Unavailable |
|||
|
#
SILENCER ASSEMBLY
510-14750-21-00
|
$36.08 | ||
|
Unavailable |
|||
|
#
NEEDLE
239-14116-20-00
|
$5.64 | ||
|
Unavailable |
|||
|
#2
GASKET
248-14623-00-00
Superseded by 248-14623-10-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#3
MUFFLER L
510-14711-02-00
|
$177.99 | ||
|
Unavailable |
|||
|
#4
SPRING, TENSION
90506-18068-00
|
$6.49 | ||
|
Unavailable |
|||
|
#5
GASKET
248-14623-00-00
Superseded by 248-14623-10-00
|
$8.49 | ||
|
Unavailable |
|||
|
#6
NUT, RING
214-14612-00-00
|
$42.72 | ||
|
Unavailable |
|||
|
#7
GASKET, EXHAUST PIPE
214-14613-00-00
Superseded by 214-14613-09-00
|
$19.99 | ||
|
Available to order. Add to View Price |
|||
|
#8
BOLT
97011-06020-00
Superseded by 97017-06020-00
|
$4.06 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#9
WASHER, SPRING
92995-06100-00
|
$3.45 | ||
|
Available to order. Add to View Price |
|||
|
#10
PLATE
363-14685-00-00
|
$5.86 | ||
|
Unavailable |
|||
|
#11
SPRING, TENSION (145-14683-00)
90507-20012-00
|
$14.99 | ||
|
Unavailable |
|||
|
#12
BOLT, HOOK
409-14684-00-00
|
$20.99 | ||
|
Unavailable |
|||
|
#13
SILENCER, EXHAUST
510-14753-10-00
|
$53.55 | ||
|
Unavailable |
|||
|
#14
CLAMP, HOSE
90460-35076-00
|
$10.45 | ||
|
Unavailable |
|||
|
#15
STAY, MUFFLER 1
483-14771-00-00
|
$29.99 | ||
|
Unavailable |
|||
|
#16
BOLT, HEX
97313-08018-00
Superseded by 90101-08691-00
|
$4.65 | ||
|
Available to order. Add to View Price |
|||
|
#17
BOLT
97313-08035-00
Superseded by 97013-08035-00
|
$6.49 | ||
|
Available to order. Add to View Price |
|||
|
#18
WASHER, SPRING
92990-08100-00
|
$5.60 | ||
|
Available to order. Add to View Price |
|||
|
#19
WASHER, PLATE
92901-08600-00
Superseded by 92990-08600-00
|
$2.70 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#20
STAY, MUFFLER 2
483-14781-02-00
Superseded by 483-14781-03-00
|
$66.99 | ||
|
Unavailable |
|||
|
#21
BOLT
97001-06018-00
Superseded by 97017-06020-00
|
$4.06 | ||
|
Unavailable |
|||
|
#22
WASHER, SPRING
92995-06100-00
|
$3.45 | ||
|
Unavailable |
|||
|
#23
BOLT, HEX
97313-08018-00
Superseded by 90101-08691-00
|
$4.65 | ||
|
Unavailable |
|||
|
#24
WASHER, SPRING
92990-08100-00
|
$5.60 | ||
|
Unavailable |
|||
|
#25
WASHER, PLATE
92901-08600-00
Superseded by 92990-08600-00
|
$2.70 | ||
|
Unavailable |
|||
|
#26
NUT
95333-08600-00
|
$3.80 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#27
SPRING, TENSION
90506-14129-00
|
$11.49 | ||
|
Unavailable |
|||
|
#28
STOPPER, MAIN STAND
278-27114-00-00
|
$9.49 | ||
|
Available to order. Add to View Price |
|||
