Governor Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
PLATE, THRUST 1
4JY-11915-01-00
Superseded by 4JY-11915-10-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#2
SCREW, PAN HEAD
98507-05012-00
Superseded by 98517-05012-00
|
$5.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#3
PUSH ROD ASSY
4SS-11990-00-00
|
$212.99 | ||
|
Available to order. Add to View Price |
|||
|
#4
COLLAR
90387-085E1-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#5
WASHER, PLATE
90201-057H5-00
|
$4.60 | ||
|
Available to order. Add to View Price |
|||
|
#6
BOLT, HEXAGON
97007-05012-00
Superseded by 97017-05012-00
|
$9.49 | ||
|
Available to order. Add to View Price |
|||
|
#7
OIL SEAL
93104-08040-00
|
$16.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#8
FORK, GOVERNOR
3JE-11922-01-00
|
$47.99 | ||
|
Available to order. Add to View Price |
|||
|
#9
BOLT
91317-04006-00
|
$10.49 | ||
|
Available to order. Add to View Price |
|||
|
#10
BEARING
93300-60801-00
Superseded by 93300-60814-00
|
$23.99 | ||
|
Available to order. Add to View Price |
|||
|
#11
SHAFT, GOVERNOR
5X4-11921-02-00
|
$61.99 | ||
|
Available to order. Add to View Price |
|||
|
#12
GEAR, GOVERNOR
5NY-11953-00-00
|
$62.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
SPRING, COMPRESSION
90501-26001-00
|
$4.75 | ||
|
Available to order. Add to View Price |
|||
|
#14
PLATE
5CU-11952-00-00
|
$18.99 | ||
|
Available to order. Add to View Price |
|||
|
#15
WASHER, PLATE
90201-150U6-00
|
$10.49 | ||
|
Available to order. Add to View Price |
|||
|
#16
COLLAR
90387-152F2-00
|
$16.49 | ||
|
Available to order. Add to View Price |
|||
|
#17
BEARING
93340-21505-00
|
$20.99 | ||
|
Available to order. Add to View Price |
|||
|
#18
RETAINER, WEIGHT
5CU-11912-00-00
|
$65.99 | ||
|
Available to order. Add to View Price |
|||
|
#19
RETAINER
5CU-11911-00-00
|
$129.99 | ||
|
Available to order. Add to View Price |
|||
|
#20
BALL
93507-16020-00
|
$2.60 | ||
|
Available to order. Add to View Price |
|||
|
#21
PIN, DOWEL
93603-14240-00
|
$2.30 | ||
|
Available to order. Add to View Price |
|||
|
#22
COLLAR
90387-103U7-00
|
$7.99 | ||
|
Available to order. Add to View Price |
|||
