Rear Brake Caliper Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
CYLINDER HEAD ASSY
4WM-2582W-00-00
Superseded by B4D-E1101-09-00
|
$433.99 | ||
|
Unavailable |
|||
|
#2
BOLT
90109-083G4-00
Superseded by 90111-08057-00
|
$2.50 | ||
|
Available to order. Add to View Price |
|||
|
#3
CALIPER ASSY, REAR 2
4WM-2580W-10-00
Superseded by 4WM-2580W-11-00
|
$448.99 | ||
|
Unavailable |
|||
|
#4
PISTON ASSY, CALIPER
1KT-25802-00-00
|
$209.99 | ||
|
Available to order. Add to View Price |
|||
|
#5
CALIPER SEAL KIT
1KT-25803-00-00
|
$63.99 | ||
|
Available to order. Add to View Price |
|||
|
#6
PISTON ASSY, CALIPER
4NK-25802-00-00
|
$187.99 | ||
|
Available to order. Add to View Price |
|||
|
#7
CALIPER SEAL KIT
4NK-25803-00-00
|
$68.99 | ||
|
Available to order. Add to View Price |
|||
|
#8
BRAKE PAD KIT
4KG-25805-00-00
|
$51.99 | ||
|
Available to order. Add to View Price |
|||
|
#9
SCREW, BLEED
1J3-25824-00-00
|
$5.99 | ||
|
Available to order. Add to View Price |
|||
|
#10
CAP
306-25825-01-00
|
$10.99 | ||
|
Available to order. Add to View Price |
|||
|
#11
COVER, DUST
1NL-25836-00-00
Superseded by 1NL-25836-01-00
|
$39.99 | ||
|
Unavailable |
|||
|
#12
PIN, PAD
3HE-25924-00-00
|
$22.99 | ||
|
Available to order. Add to View Price |
|||
|
#13
CLIP
3GM-25925-00-00
|
$12.99 | ||
|
Available to order. Add to View Price |
|||
|
#14
SUPPORT, PAD
1NL-25919-00-00
|
$26.99 | ||
|
Available to order. Add to View Price |
|||
|
#15
BOLT, FLANGE
90105-10638-00
|
$8.49 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#16
BRACKET, CALIPER
4WM-25819-00-00
|
$278.99 | ||
|
Available to order. Add to View Price |
|||
|
#17
BOLT, FLANGE
95827-10050-00
Superseded by 95817-10050-00
|
$8.49 | ||
|
Available to order. Add to View Price |
|||
|
#18
WASHER, PLATE
90201-10140-00
Superseded by 90201-105R9-00
|
$10.49 | ||
|
Available to order. Add to View Price |
|||
