Points + Advancer 80 Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
BASE, POINTS
12332-324-000
|
$50.61 | ||
|
Unavailable |
|||
|
#2
GASKET, POINTS BASE (AS)
12339-383-000
Superseded by 12339-383-306
|
$3.70 | ||
|
Unavailable |
|||
|
#2
GASKET, POINTS BASE (AS)
12339-383-306
|
$3.70 | ||
|
Unavailable |
|||
|
#3
POINTS ASSY. (TOYO)
30200-383-871
|
$28.10 | ||
|
Unavailable |
|||
|
#4
PLATE, POINTS BASE (NOT AVAILABLE)
30201-383-871
|
$19.97 | ||
|
Unavailable |
|||
|
#5
POINTS (TOYO)
30202-107-154
|
$33.80 | ||
|
Available to order. Add to View Price |
|||
|
#6
FELT, OIL (TOYO)
30205-300-154
|
$1.73 | ||
|
Unavailable |
|||
|
#7
ADVANCER ASSY., SPARK (TOYO)
30220-383-871
|
$129.16 | ||
|
Unavailable |
|||
|
#8
COVER, POINTS (NOT AVAILABLE)
30370-383-870
|
$17.65 | ||
|
Unavailable |
|||
|
#9
GASKET, POINTS COVER
30372-107-000
Superseded by 30372-107-307
|
$3.33 | ||
|
Available to order. Add to View Price |
|||
|
#9
GASKET, POINTS COVER
30372-107-307
|
$3.33 | ||
|
Unavailable |
|||
|
#10
WASHER (5MM)
90482-028-000
|
$2.51 | ||
|
Available to order. Add to View Price |
|||
|
#11
WASHER, SPARK ADVANCER SETTING
90486-028-000
|
$2.55 | ||
|
Available to order. Add to View Price |
|||
|
#12
OIL SEAL (15X25X7)
91202-107-003
Superseded by 91203-965-003
|
$8.05 | ||
|
Available to order. Add to View Price |
|||
|
#12
OIL SEAL (15X25X7)
91203-965-003
|
$8.05 | ||
|
Unavailable |
|||
|
#13
O-RING (75X2.5)
91301-107-000
|
$6.13 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#14
BOLT, HEX. (6X14) BOLT, FLANGE (6X14)
92000-06014
Superseded by 92101-06014-0A
|
$1.52 | ||
|
Available to order. Add to View Price |
|||
|
#14
BOLT, HEX. (6X14)
92101-06014-0A
|
$1.52 | ||
|
Unavailable |
|||
|
#15
SCREW, PAN (5X12)
93500-05012-0A
|
$0.95 | ||
|
Available to order. Add to View Price |
|||
|
#16
SCREW, PAN (6X25)
93500-06025
Superseded by 93500-06025-0A
|
$1.25 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#17
SCREW, OVAL (5X20)
93700-05020-0A
|
$0.53 | ||
|
Unavailable |
|||
|
#18
WASHER, PLAIN (4MM)
94101-04000
|
$1.03 | ||
|
Available to order. Add to View Price |
|||
|
#19
WASHER, SPRING (4MM)
94111-04000
|
$1.12 | ||
|
Available to order. Add to View Price |
|||
|
#20
SCREW, PAN (4X6)
99500-04006-0A
Superseded by 93500-04006-0A
|
$0.87 | ||
|
Available to order. Add to View Price |
|||
|
#20
SCREW, PAN (4X6)
99500-04007-0A
Superseded by 93500-04006-0A
|
$0.87 | ||
|
Unavailable |
|||
