08- Drive System, Rear Diagram
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
Rear Wheel Axle
V23511MAA020
|
$211.99 | ||
|
Available to order. Add to View Price |
|||
|
#2
LH Spacer Collar
V44160MAA020BK
|
$26.49 | ||
|
Available to order. Add to View Price |
|||
|
#3
RH Spacer Collar
V44150MAA010BK
|
$24.99 | ||
|
Available to order. Add to View Price |
|||
|
#4
Cam Chain Sprocket 40T
V15239DGF00HLL
|
$84.99 | ||
|
Available to order. Add to View Price |
|||
|
#5
Cam Chain Sprocket 16T
V15237DGF010
|
$45.49 | ||
|
Available to order. Add to View Price |
|||
|
#6
Rear Wheel Axle Seat Ass'y
V52350MAA100BK
|
$190.49 | ||
|
Available to order. Add to View Price |
|||
|
#7
Oil Seal
V91203MAA000
|
$14.28 | ||
|
Available to order. Add to View Price |
|||
|
#8
Radial Ball Bearing
A961006006ZZ
Superseded by V961006006ZZ
|
$43.49 | ||
|
Available to order. Add to View Price |
|||
|
#9
Spacer
V45620MAA000
Superseded by V44620MAA000
|
$23.49 | ||
|
Available to order. Add to View Price |
|||
|
#10
Spacer
V51312MAA010
|
$6.35 | ||
|
Available to order. Add to View Price |
|||
|
#11
Hex. Flange Bolt
V960001202801LL
|
$6.35 | ||
|
Available to order. Add to View Price |
|||
|
#12
Hexagonal Nut M12
A9035012000
Superseded by A9035012000G
|
$6.67 | ||
|
Available to order. Add to View Price |
|||
|
#13
Screw
V9200006010
|
$2.19 | ||
|
Available to order. Add to View Price |
|||
|
#14
Washer
V941011326020
|
$7.73 | ||
|
Available to order. Add to View Price |
|||
|
#15
Fixing Plate
V128114DM00
|
$11.05 | ||
|
Available to order. Add to View Price |
|||
