2000 Suzuki SV 650 WIRING HARNESS (SV650SX/SY/SK1/SK2) OEM Parts Diagram
Accessory
+
Air & Fuel
+
Body, Fairing & Fender
+
Brakes
+
Cooling System
+
Dash & Gauges
+
Drive & Transmission
+
Electrical
+
Engine
+
Exhaust
+
Foot Control
+
Frame
+
Handlebars & Controls
+
Other
+
Seat
+
Suspension
+
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
HARNESS, WIRING NO.1
36610-19F00
|
$375.34 | ||
|
Unavailable |
|||
|
#1
HARNESS, WIRING NO.1
36610-19F40
|
$451.53 | ||
|
Unavailable |
|||
|
#1
HARNESS, WIRING NO.1
36610-19F60
|
$426.50 | ||
|
Unavailable |
|||
|
#2
FUSE (10A)
09481-10501
|
$2.00 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#2
FUSE (15A)
09481-15501
|
$2.00 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#3
GUIDE, WIRING HARNESS
36619-33E00
|
$13.43 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#4
HARNESS, WIRING NO.2
36620-19F10
|
$191.02 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#4
HARNESS, WIRING NO.2
36620-19F30
|
$139.21 | ||
|
Unavailable |
|||
|
#5
COVER, SPEEDOMETER COUPLER
36618-33E00
|
$7.68 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#5A
HOLDER, COUPLER
36687-19F00
|
$4.36 | ||
|
Unavailable |
|||
|
#6
CLAMP (L:65)
09404-06432
Superseded by 09404-06039
|
$1.71 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#6
CLAMP (L:135)
09404-06435
|
$3.10 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#7
CLAMP (L:90)
09407-11402
|
$1.75 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#7
CLAMP
09407-17401
Superseded by 09407-17402
|
$3.31 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#8
CLAMP (L:125)
09407-14403
|
$2.21 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#8
CLAMP (L:165)
09407-18402
|
$2.15 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#8A
BOLT, CLAMP
01550-06123
Superseded by 01550-0612A
|
$1.94 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#9
LOCK SET
37101-19830
|
$438.27 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#9
LOCK SET
37101-19840
|
$367.64 | ||
|
Unavailable |
|||
|
#10
LOCK ASSY, STEERING
37100-19F00
|
$218.63 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#11
BOLT (8X20)
09139-08016
|
$3.34 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#12
SWITCH ASSY, STOP LAMP
37740-31D00
|
$29.23 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#12
SWITCH ASSY, STOP LAMP
37740-19F00
|
$27.40 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#13
SPRING
09443-06005
|
$2.84 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#14
BRACKET, STOP LAMP SWITCH
43251-19F00
|
$6.21 | ||
|
Unavailable |
|||
|
#15
BOLT, CLAMP
01550-06123
Superseded by 01550-0612A
|
$1.94 | ||
|
Unavailable |
|||
|
#16
SWITCH ASSY,SID
37840-19F00
Superseded by 37840-19F01
|
$72.95 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#17
BOLT (6X20)
37849-19F00
Superseded by 09103-06248
|
$1.93 | ||
|
Unavailable |
|||
|
#17
BOLT (6X20)
09103-06248
|
$1.93 | ||
|
Unavailable |
|||
|
#18
NUT
08316-10063
Superseded by 08316-1006B
|
$2.47 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#19
HORN ASSY
38500-02F60
|
$76.83 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#19
HORN ASSY
38500-19F00
|
$61.46 | ||
|
Unavailable |
|||
|
#20
BRACKET, HORN
38590-19F00
|
$10.86 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#21
BOLT, CLAMP
01550-06123
Superseded by 01550-0612A
|
$1.94 | ||
|
Unavailable |
|||
|
#22
BOLT
01550-08123
Superseded by 01550-0812A
|
$2.28 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#23
KEY,.BLANK
37146-33E00
|
$21.95 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#24
WIRE, STARTER CONTROL
36854-19F00
|
$55.34 | ||
|
Unavailable |
|||
