2006 Suzuki RM 125 REAR SHOCK ABSORBER (MODEL K3) OEM Parts Diagram
Accessory
+
Air & Fuel
+
Body, Fairing & Fender
+
Brakes
+
Cooling System
+
Drive & Transmission
+
Electrical
+
Engine
+
Exhaust
+
Foot Control
+
Frame
+
Handlebars & Controls
+
Labels
+
Seat
+
Suspension
+
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
ABSORBER ASSY, RR SHOCK (RED)
62100-36F80-37W
|
$1,519.77 | ||
|
Unavailable |
|||
|
#1
ABSORBER ASSY, RR SHOCK (RED)
62100-36F70-37W
|
|||
|
Unavailable |
|||
|
#2
SPRING (K=4.9)
62211-36F30
|
$355.07 | ||
|
Unavailable |
|||
|
#3
BEARING (16X22X12)
09263-16033
|
$20.21 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#4
SPACER, BEARING RH
62684-36F00
|
$20.21 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#5
SPACER, BEARING LH
62685-36F00
|
$13.83 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#6
SEAL, DUST RH
09284-16005
|
$6.94 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#7
ROD, PISTON
62120-36F70
|
$767.27 | ||
|
Unavailable |
|||
|
#8
O RING SET
62150-36EB0
|
$62.53 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#9
RING, STOPPER
62279-36E80
|
$7.04 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#10
ADJUSTER SET
62190-36F00
|
$102.19 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#11
SPRING SEAT SET
62220-36F00
|
$75.36 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#12
RING, STOPPER
62278-36E00
|
$7.53 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#13
CAP
51294-20400
|
$6.44 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#14
BLADDER
62273-36F00
|
$56.04 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#15
CAP, CHAMBER
62275-36F00
|
|||
|
Unavailable |
|||
|
#16
BOLT, PLUG
62130-36F60
|
$163.51 | ||
|
Unavailable |
|||
|
#17
O RING
62131-28E00
|
$4.36 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#18
O RING
51174-43D00
|
$4.23 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#19
BOLT
09103-10329
|
$4.64 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#20
NUT, REAR SWGARM BRACKET
09159-10058
Superseded by 09159-10115
|
$3.54 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#21
BOLT
09103-10325
|
$3.87 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#22
NUT
09159-10067
|
$6.09 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#23
SPRING (SOFT,K=4.6)
62211-36EB0
|
$239.88 | ||
|
Unavailable |
|||
|
#23
SPRING (HARD,K=5.0)
62211-36F00
|
$239.88 | ||
|
Unavailable |
|||
|
#23
SPRING (HARD,K=5.2)
62211-36E80
|
$426.58 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#23
SPRING (SOFT,K=4.8)
62211-36F10
|
$297.52 | ||
|
Unavailable |
|||
