2006 Suzuki RM 125 FUEL TANK (MODEL K4/K5/K6) OEM Parts Diagram
Accessory
+
Air & Fuel
+
Body, Fairing & Fender
+
Brakes
+
Cooling System
+
Drive & Transmission
+
Electrical
+
Engine
+
Exhaust
+
Foot Control
+
Frame
+
Handlebars & Controls
+
Labels
+
Seat
+
Suspension
+
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
TANK, FUEL (YELLOW)
44110-36F10-YU1
|
$382.71 | ||
|
Unavailable |
|||
|
#1
TANK, FUEL (YELLOW)
44110-36F20-YU1
Superseded by 44110-36F21-YU1
|
$474.81 | ||
|
Unavailable |
|||
|
#2
BRACKET, FRONT
44131-27C01
|
$13.00 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#3
SCREW
02142-06123
Superseded by 02142-0612A
|
$1.34 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#4
HOOK, SEAT FRONT
44132-37F00
|
$7.89 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#4
HOOK, SEAT FRONT
44132-37F10
|
$10.11 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#5
SCREW
02142-06163
Superseded by 02142-0616A
|
$1.34 | ||
|
In Stock: Ready to ship. Add to View Price |
|||
|
#5
SCREW
02122-06203
Superseded by 02122-0620A
|
$1.40 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#6
SCREW, TANK BAND
09139-06134
|
$2.22 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#7
CAP, FUEL TANK
44210-37F00
|
$30.26 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#8
GASKET,FUEL TANK FILLER CAP
44248-27C00
Superseded by 44248-27C01
|
$4.35 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#9
HOSE,5X8.2X600
09352-50823-600
Superseded by 44420-44AR0
|
$9.22 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#10
CUSHION
44541-26C00
|
$15.77 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#11
CUSHION
44541-36F00
|
$10.89 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#11
CUSHION
44541-37F00
|
$13.80 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#12
CLAMP
09407-30402
|
$4.07 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#13
CUSHION, REAR
44542-36F00
|
$7.00 | ||
|
Unavailable |
|||
|
#13
CUSHION, REAR
44542-37F00
|
$8.70 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#14
CLAMP, REAR
09407-25402
|
$4.62 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#15
BAND, REAR
44560-27C00
|
$7.94 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#16
CUSHION (8.7X26X14)
14762-01B01
Superseded by 14762-01B02
|
$3.86 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#17
BOLT, FRONT
09116-06195
|
$3.12 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#18
SPACER
09180-06268
|
$2.00 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#19
CUSHION, SIDE
33652-19F00
|
$4.49 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#20
TAPE SET
68110-37F30-NT3
|
$139.21 | ||
|
Unavailable |
|||
|
#21
TAPE SET
68110-37F40-AZR
|
$208.74 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#22
TAPE SET
68110-37F50-CFK
|
$251.93 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
