2009 Suzuki DR-Z 125 FUEL TANK COVER (MODEL K9) OEM Parts Diagram
Accessory
+
Air & Fuel
+
Body, Fairing & Fender
+
Brakes
+
Drive & Transmission
+
Electrical
+
Engine
+
Exhaust
+
Foot Control
+
Frame
+
Handlebars & Controls
+
Labels
+
Seat
+
Suspension
+
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
COVER, FUEL TANK RH (YELLOW)
44271-08GA0-YU1
|
$50.23 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#1
COVER, FUEL TANK RH (BLACK)
44271-08GA0-019
|
$50.23 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#2
COVER, FUEL TANK LH (YELLOW)
44281-08GA0-YU1
|
$50.23 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#2
COVER, FUEL TANK LH (BLACK)
44281-08GA0-019
|
$50.23 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#3
TAPE, COVER RH
68115-08GC0-FYF
|
$110.14 | ||
|
Unavailable |
|||
|
#4
TAPE, COVER RH
68115-08GB0-GGL
|
$107.94 | ||
|
Unavailable |
|||
|
#5
TAPE, COVER LH
68116-08GC0-FYF
|
$107.94 | ||
|
Unavailable |
|||
|
#6
TAPE, COVER LH
68116-08GB0-GGL
|
$107.94 | ||
|
Unavailable |
|||
|
#7
CUSHION
44294-14H00
|
$4.14 | ||
|
Unavailable |
|||
|
#8
BRACKET, FRONT
44160-08GA0
|
$145.43 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#9
BOLT, BRACKET
09116-06186
|
$2.47 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#10
SPACER
09180-06268
|
$2.00 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#11
CUSHION,FUEL TANK SIDE
44512-04F00
Superseded by 44512-04F01
|
$3.75 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#12
CLIP (BLACK)
09409-08308-5ES
|
$1.94 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#13
BOLT
01547-0616A
|
$2.00 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#14
WSHER
09169-06053
|
$1.09 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
