1990 Suzuki DR650SL REAR SWINGING ARM OEM Parts Diagram
Accessory
+
Air & Fuel
+
Body, Fairing & Fender
+
Brakes
+
Dash & Gauges
+
Drive & Transmission
+
Electrical
+
Engine
+
Exhaust
+
Foot Control
+
Frame
+
Handlebars & Controls
+
Other
+
Seat
+
Suspension
+
| Item | MSRP | Qty | |
|---|---|---|---|
|
#1
SWINGINGARM ASS
61000-14A70-13L
Superseded by 61000-12D31-13L
|
$696.21 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#2
BEARING
09263-22022
|
$22.52 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#3
SPACER, CENTER
61282-14A00
|
$10.77 | ||
|
Unavailable |
|||
|
#4
SPACER
61251-32410
|
$12.43 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#5
WASHER
08211-16341
|
$2.36 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#6
SEAL
61262-14A00
Superseded by 61262-14A01
|
$6.35 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#7
SHAFT
61211-12D00
Superseded by 61211-12D10
|
$41.24 | ||
|
Unavailable |
|||
|
#8
WASHER
08322-11165
|
$0.53 | ||
|
Unavailable |
|||
|
#9
NUT
08319-21165
|
$3.13 | ||
|
Unavailable |
|||
|
#10
BUFFER,CHAIN TC
61273-12D00
Superseded by 61273-12D21
|
$52.94 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#11
BOLT
61275-44B00
|
$2.96 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#12
WASHER (5.5X14X1.20)
09160-05036
Superseded by 09160-05048
|
$1.68 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#13
SPACER
09180-06165
Superseded by 09180-06257
|
$2.38 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#14
NUT
08319-31056
Superseded by 08319-3105B
|
$3.52 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#15
CASE, CHAIN
61310-14A00
|
$53.00 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#16
BOLT
01517-06105
Superseded by 01550-0610A
|
$1.94 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#17
WASHER
09169-06026
|
$1.88 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#18
GUIDE, CHAIN
61341-14A03
|
$27.65 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#19
BOLT
01517-06128
Superseded by 01550-06127
|
$2.28 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#20
BOLT
01517-06167
Superseded by 01550-06167
|
$2.28 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
