1990 Suzuki DR650SL REAR CALIPER OEM Parts Diagram
Accessory
+
Air & Fuel
+
Body, Fairing & Fender
+
Brakes
+
Dash & Gauges
+
Drive & Transmission
+
Electrical
+
Engine
+
Exhaust
+
Foot Control
+
Frame
+
Handlebars & Controls
+
Other
+
Seat
+
Suspension
+
| Item | MSRP | Qty | |
|---|---|---|---|
|
#
CALIPER ASSY, REAR
69100-44B00
Superseded by 69100-12D01
|
$277.75 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#1
PISTON SET
69100-44850
Superseded by 69100-44851
|
$46.60 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#2
SEAL,PISTON
59107-04A00
Superseded by 59107-40F00
|
$7.47 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#3
SEAL, WIPER
59108-04A00
|
$7.34 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#4
PAD SET
69100-44860
Superseded by 69100-12810
|
$42.78 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#5
SPRING
69115-44B00
|
$6.95 | ||
|
Unavailable |
|||
|
#6
GUIDE, PAD
69116-44B00
|
$8.71 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#7
PIN
69141-44B00
Superseded by 69141-44B02
|
$10.94 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#8
CLIP
69142-45000
|
$4.49 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#9
BOOT
59312-36500
|
$5.22 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#10
INSULATOR
59313-36500
|
$6.21 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#11
BRACKET
69150-44B00
|
$79.88 | ||
|
Unavailable |
|||
|
#12
BLEEDER
59121-18410
|
$9.03 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#13
CAP, BLEEDER
59122-18410
Superseded by 55156-66310
|
$5.34 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#14
BOLT
09103-08259
|
$3.79 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
