1990 Suzuki DR650SL FRONT FORK OEM Parts Diagram
Accessory
+
Air & Fuel
+
Body, Fairing & Fender
+
Brakes
+
Dash & Gauges
+
Drive & Transmission
+
Electrical
+
Engine
+
Exhaust
+
Foot Control
+
Frame
+
Handlebars & Controls
+
Other
+
Seat
+
Suspension
+
| Item | MSRP | Qty | |
|---|---|---|---|
|
#
DAMPER ASSY, RH
51103-14A20
|
$446.14 | ||
|
Unavailable |
|||
|
#
DAMPER ASSY, LH
51104-14A20
|
$538.05 | ||
|
Unavailable |
|||
|
#1
TUBE, OUTER RH
51130-12D00
|
$180.24 | ||
|
Unavailable |
|||
|
#2
TUBE, OUTER LH
51140-12D00
|
$211.12 | ||
|
Unavailable |
|||
|
#3
METAL, SLIDE
51167-28C00
Superseded by 51167-26E10
|
$25.26 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#4
WASHER, LOWER
51158-05A00
|
$6.00 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#5
OIL SEAL
51153-44B00
|
$21.49 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#6
DUST SEAL
51173-44B00
|
$18.29 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#7
WASHER, UPPER
51158-44B00
|
$6.31 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#8
SNAP RING
51156-49440
|
$5.22 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#9
PIECE, OIL LOCK
51195-12D00
|
$10.68 | ||
|
Unavailable |
|||
|
#10
BOLT
51147-14200
|
$5.06 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#11
GASKET
51148-14200
|
$2.16 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#12
CYLINDER
51190-14A20
|
$67.41 | ||
|
Unavailable |
|||
|
#13
SPRING
51177-12D00
|
$5.13 | ||
|
Unavailable |
|||
|
#14
RING, PISTON
51196-24A00
|
$7.43 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#15
TUBE, INNER
51110-14A20
|
$161.10 | ||
|
Unavailable |
|||
|
#16
.PISTON
51121-28C00
Superseded by 51121-26E10
|
$31.13 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#17
SPRING
51171-14A20
|
$60.45 | ||
|
Unavailable |
|||
|
#18
GUIDE, SPRING
51172-12D00
|
$5.48 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#19
SPACER
51176-14A20
|
$6.45 | ||
|
Unavailable |
|||
|
#20
CAP
51351-14A20
|
$48.26 | ||
|
Unavailable |
|||
|
#21
O RING
51117-06C10
Superseded by 09280-32001
|
$2.01 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#22
CAP, VALVE
51294-20400
|
$6.44 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#23
BOLT, RH
51138-44B00
|
$3.72 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#24
BOOT (BLUE)
51571-12D00-38K
|
$93.25 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
|
#25
BAND, BOOT UPPER
51575-12D00
|
$7.47 | ||
|
Available: Ships in 7-12 days. Add to View Price |
|||
