KTM Releases Details On 2017 Mini Motos
The
Supercross season just ended with Red Bull KTM rider Ryan Dungey
securing his third SX Championship title. Now, as we head into the
outdoors series, AKA the Lucas Oil Pro Motocross Championship,
Dungey has his eyes set on a double-double as he looks attain
back-to-back championships in both the SX and MX series.
Winning Combo
The Dungey/KTM team has been a great
combination winning a multitude of races and accolades. Dungey
himself has been an excellent ambassador not only for the KTM brand
but for motocross racing as a whole--just this year he made it onto
the cover of the Wheaties box, the first time ever for a motocross
athlete. Obviously a highly skilled rider, its Dungey's
determination, unwillingness to give up, and his ability to be
extremely competitive yet a true gentleman on and off the track
that makes him a fan favorite. An inspiration for young riders and
a role model that parents can be easily get behind, Dungey's impact
and influence is immeasurable. And with KTM's reputation as a
distinguished brand and quality manufacturer with a focus on
optimal performance and technology, the two make a great pair.
As school is about to get out and the summer riding season is about
to kick off, KTM has announced the first batch of its 2017 models
starting with the small displacement kids dirt bikes. Who knows,
letting your little one toss a leg over one of these motocross
bikes could help ignite their inner Dungey.
2017 KTM 50 SX
Mini
Built for the smallest of racers, the 50 SX Mini incorporates much of the technology of the 50 SX with a more friendly power delivery, smaller wheels and a lower seat height. It is a genuine dirt bike that, like its bigger siblings, is produced with top-quality components. This makes the 50 SX Mini the best choice for a young rider's first KTM. The 2-stroke engine delivers steady, controllable power, incorporating an automatic clutch that allows the rider to concentrate on the terrain, not shifting. Just like the entire READY TO RACE KTM product line, the 50 SX Mini has slim bodywork for the best possible ergonomics, looking just like the biggest and baddest 450 SX-F.
Highlights:
-A 3-shaft engine design keeps the crankshaft close to the bike's
center of gravity for quick handling along with room for an
optimized reed valve angle for maximum performance
-Bodywork that mimics the full-size 2017 SX-F line that gives the
50 SX mini a slim profile for excellent ergonomics and handling
-Front and rear hydraulic brakes by Formula combined with
lightweight WAVE discs are powerful with feedback that gives
control for any skill level
-A centrifugal multi-disc automatic clutch provides manageable
acceleration and can be adjusted to the track conditions in minutes
without tools
-Super lightweight, black anodized aluminum rims are matched to
MAXXIS tires for maximum grip
Specs:
Engine Type: Single Cylinder, 2-Stroke
Displacement: 49 cc
Bore/Stroke: 39.5/40.0 mm
Starter: Kickstarter
Transmission: Rigid 1-Stage Reduction Gear
Fuel System: Dell'Orto PVHA 12 XS
Lubrication: Premix 60:1
Primary Ratio: 33:61 Straight Cut Reduction Gear
Final Drive: 10:42
Cooling: Liquid Cooling
Clutch: Centrifugal Clutch (Adjustable)
Ignition: Selettra 2p D36
Frame: Central Tube Frame, Chrome Molybdenum
Subframe: Steel
Handlebar: Renthal, Aluminum Ø 22mm
Front Suspension: WP USD Ø 35mm
Rear Suspension: WP Monoshock
Suspension Travel Front/Rear: 100 mm/3.9 in; 147 mm/5.6 in
Front/Rear Brakes: Disc Brake 160 mm; 160 mm
Front/Rear Rims: 1.60 x 10", 1.60 x 10"
Front/Rear Tires: 2.50 x 10"; 2.75 x 10"
Chain: 1/2 x 3/16 in
Silencer: Aluminum
Steering Head Angle: 23.6º
Triple Clamp Offset: 22 mm
Wheelbase: 914± 10 mm / 36 ± 0.4 in
Ground Clearance: 184 mm / 7.2 in
Seat Height: 558 mm / 22 in
Tank Capacity, Approx: 2.1L / 0.55 gal
Weight (without fuel), Approx: 40 kg/ 88.2 lbs
2017 KTM 50SX
The 50 SX is a true READY TO RACE KTM for young MX riders. It is a genuine dirt bike that, like its bigger siblings, is produced with top-quality components. This makes the 50 SX the first choice as a stepping stone into the world of MX or for the first racing step on the ladder. With the youngster in mind this package has an engine that delivers steady, controllable power, incorporating an automatic clutch that allows the rider to concentrate on the track, not shifting. This year's model features revolutionary WP AER 35 front forks, fully adjustable rear suspension, a new exhaust, ultra-cool graphics and detail improvements that make going fast fun.
Highlights:
-New WP AER 35 air-sprung fork is easily adjustable for different
rider sizes as well as track conditions
-New fully adjustable rear suspension to match the performance of
the WP AER 35 fork
-Newly developed exhaust pipe provides better power delivery and
more peak power over the entire rev range
-A 3-shaft engine design keeps the crankshaft close to the bike's
center of gravity for quick handling along with room for an
optimized reed valve angle for maximum performance
-Bodywork that mimics the full-size 2017 SX-F line that gives the
50 SX a slim profile for excellent ergonomics and handling
-Front and rear hydraulic brakes by Formula combined with
lightweight WAVE discs are powerful with feedback that gives
control for any skill level
-A centrifugal multi-disc automatic clutch provides manageable
acceleration and can be adjusted to the track conditions in minutes
without tools
-Super lightweight, black anodized aluminum rims are matched to
MAXXIS tires for maximum grip
Specs:
Engine Type: Single Cylinder, 2-Stroke
Displacement: 49 cc
Bore/Stroke: 39.5/40.0 mm
Starter: Kickstarter
Transmission: Rigid 1-Stage Reduction Gear
Fuel System: Dell'Orto PHBG 19 BS
Lubrication: Premix 60:1
Primary Ratio: 33:61 Straight Cut Reduction Gear
Final Drive: 11:40
Cooling: Liquid Cooling
Clutch: Centrifugal Clutch (Adjustable)
Ignition: Selettra 2p D36
Frame: Central Tube Frame, Chrome Molybdenum
Subframe: Steel
Handlebar: Renthal, Aluminum Ø 22mm
Front Suspension: WP AER 35 USD Ø 35mm
Rear Suspension: WP Monoshock
Suspension Travel Front/Rear: 205 mm/8.07 in; 185 mm/7.28 in
Front/Rear Brakes: Disc Brake 160 mm; 160 mm
Front/Rear Rims: 1.50 x 12", 1.60 x 10"
Front/Rear Tires: 60/100 x 12"; 2.75 x 10"
Chain: 1/2 x 3/16 in
Silencer: Aluminum
Steering Head Angle: 24.0º
Triple Clamp Offset: 22 mm
Wheelbase: 1,032mm ± 10 mm / 40.6 ± 0.4 in
Ground Clearance: 252mm / 9.92 in
Seat Height: 684 mm / 26.9 in
Tank Capacity, Approx: 2.3L / 0.61 gal
Weight (without fuel), Approx: 40.8 kg/ 90 lbs
Rear Suspension: WP Monoshock
Suspension Travel Front/Rear: 171 mm/6.73 in; 100 mm/3.94 in
2017 KTM 65SX
The 65 SX is a fully-fledged piece of racing kit for young pilots. This year's top mini features revolutionary WP AER 35 front forks, cool graphics and detailed improvements that set the standard in terms of power, riding dynamics, equipment and craftsmanship. Further weight reduction from the new WP AER 35 fork make the 65 SX even sharper on the track. Like its larger counterparts, the 65 SX is truly READY TO RACE for its young competitors.
Highlights:
-NEW WP AER 35 air-sprung front fork is 1.7 pounds lighter and
makes adjustments for the rider size and track easy
-Sleek bodywork that provides excellent ergonomics for the ultimate
in control
-NEW graphics to match the full-size SX models
-The 65 SX benefits from cutting-edge 2-stroke technology and an
easy to shift 6-speed transmission with a hydraulic clutch.
-A WP PDS monoshock guarantees optimum damping characteristics and
outstanding stability. The rear wheel travel is 270mm.
-With adjustable compression and rebound, the suspension can be set
up precisely for the rider and track in no time.
-The 65 SX is fitted front and rear with massive four-piston
calipers that grip lightweight Wave brake discs of 198mm front and
160mm rear diameter.
-Like the big KTM factory racers, the 65 SX has super lightweight,
black anodized, aluminum rims providing the highest strength.
-MAXXIS knobby tires provide superb grip in any terrain
Specs:
Engine Type: Single Cylinder, 2-Stroke
Displacement: 64.9 cc
Bore / Stroke: 45.0 / 40.8 mm
Starter: Kickstarter
Transmission: 6 Gears
Fuel System: Mikuni TM 24-505
Lubrication: Premix 60:1
Primary Ratio: 23:75
Final Drive: 14:48
Cooling: Liquid Cooling
Clutch: Wet Multi-Disc Clutch, Formula Hydraulics
Ignition: AET Digital
Frame: Central Tube Frame, Chrome Molybdenum
Subframe: Aluminum
Handlebar: Renthal, Aluminum Ø 22mm
Front Suspension: WP AER 35 USD Ø 35mm
Rear Suspension: WP Monoshock
Suspension Travel Front/Rear: 217 mm/8.5 in; 270 mm/10.6 in
Front/Rear Brakes: Disc Brake 198 mm; 220 mm
Front/Rear Rims: 1.60 x 14", 1.60 x 12"
Front/Rear Tires: 60/100-14"; 80/100-12"
Chain: 1/2 x 1/4 in
Silencer: Aluminum
Steering Head Angle: 25.5º
Triple Clamp Offset: 22 mm
Wheelbase: 1,137 mm ± 10 mm / 44.8 in ± 0.4 in
Ground Clearance: 280 mm / 11 in
Seat Height: 750 mm / 29.5 in
Tank Capacity, Approx: 3.5 L / 0.92 gal
Weight (without fuel), Approx: 52.2 kg / 115.1 lbs
2017 KTM 85SX
The riders of the junior class are no longer beginners. These are future champions fighting for victory, no matter if it is the AMA Amateur National Title or Junior Motocross World Championship. In this scene, the 85 SX is considered the weapon of choice. With the most powerful engine in the field and a super lightweight, stable chassis, the only real competition comes from others racing on the 85 SX.
Highlights
-The 85 SX benefits from cutting-edge 2-stroke technology and a
precise 6-speed transmission with a hydraulic clutch for
superiority on the race track.
-The Formula braking system with radial calipers, four pistons in
front, two in the rear, matched with lightweight Wave 240 mm front
and a 210 rear brake disc set the standard in terms of controlled
action and braking performance.
-What is good for the bigger KTM off-road bikes is also good for
the 85 SX - an air filter change can be done within seconds without
tools.
-Made of top quality chromoly steel with a lightweight, bolt-on
aluminum rear subframe, the 85 SX frame ensures maximum stability
at a minimum weight
-WP 43mm upside-down forks provide 270mm of travel, while a PDS
monoshock for the rear provides optimum traction and surface
contact.
-Ergonomics and function of the bodywork is designed in such a way
as to achieve complete harmony between rider and bike.
-NEW graphics provide a sleek and up-to-date look bases on the
full-sized SX line.
Specs:
Engine Type: Single Cylinder, 2-Stroke
Displacement: 84.9 cc
Bore / Stroke: 47 / 48.95 mm
Starter: Kickstarter
Transmission: 6 Gears
Fuel System: Mikuni TM 24-505
Lubrication: Premix 40:1
Primary Ratio: 19:66
Final Drive: 14:46
Cooling: Liquid Cooling
Clutch: Wet Multi-Disc Clutch, Formula Hydraulics
Ignition: Moric Digital 2M1
Frame: Central Tube Frame, Chrome Molybdenum
Subframe: Aluminum
Handlebar: Tapered Aluminum Ø 28/22mm
Front Suspension: WP USD Ø 43 mm
Rear Suspension: WP PDS Monoshock
Suspension Travel Front/Rear: 270 mm/10.6 in; 300 mm/11.8 in
Front/Rear Brakes: Disc Brake 220 mm; 210 mm
Front/Rear Rims: 1.40 x 17", 1.60 x 14"
Front/Rear Tires: 70/100-17"; 90/100-14"
Chain: 1/2 x 5/16 in
Silencer: Aluminum
Steering Head Angle: 24º
Triple Clamp Offset: 14 mm
Wheelbase: 1,290 mm ± 10 mm / 50.8 in ± 0.4 in
Ground Clearance: 352 mm / 13.9 in
Seat Height: 855 mm / 33.7 in
Tank Capacity, Approx: 5 L / 1.3 gal
Weight (without fuel), Approx: 67.5 kg / 148.8 lbs
