2016 KTM SX-F Factory Edition Bikes, Not Just For Factory Riders

Posted on January 7, 2016 by TwoWheelMania.
Ryan Dungey on 2016 KTM 450 SX-F Factory Edition Ryan Dungey on his 2016 KTM 450 SX-F Factory Edition race bike - Photo: Kit Palmer

KTM factory riders Ryan Dungey, Marvin Masquin, Justin Hill and Jessy Nelson recently got a chance to see what their new rides for the 2016 season would be at KTM's test track in Corona, California.

The 2016 KTM 450 SX-F and 250 SX-F Factory Edition models remain similar to their 2015 counterparts. However, the differences are noticeable. Both bikes will shave off a few pounds thanks to new forks and new mufflers.

The 2016 models are now fitted with WP AER 48 air forks. These forks are about 3.1 pounds lighter than the previous spring fork, which is definitely good news for 450cc riders Dungey and Musquin. The KTM dirt bike was already the lightest of the 450 class in 2015.

Both bikes also get lighter mufflers. The 250 has a new FMF muffler while the 450 gets an Akrapovic model.

All told, both bikes shed about 4 pounds from the 2015 models, which ought to keep KTM's factory riders competitive on the motocross and supercross series in the coming year.

[vehicle source="ktm" img="https://www.chapmoto.com/wp/wp-content/uploads/2015/12/2016-KTM-450-SX-F-Factory-Edition.jpg" url="http://www.ktm.com/us/mx/450-sx-f-factory-edition-2016/"]

Year|2016$Manufacturer|KTM$Model Name|450 SX-F Factory Edition$

Engine

  • Design

    1-cylinder, 4-stroke engine

  • Displacement

    449.9 cm³

  • Bore

    95 mm

  • Stroke

    63.4 mm

  • Starter

    Electric starter

  • Transmission

    4-speed

  • Primary drive

    31:76

  • Secondary gear ratio

    13:48

  • Clutch

    Wet, DDS multi-disc clutch, Brembo hydraulics

  • EMS

    Keihin EMS

Chassis

  • Frame design

    25CrMo4 steel central-tube frame

  • Front suspension

    WP-USD, AER 48, Ø 48 mm

  • Rear suspension

    WP shock absorber with linkage

  • Suspension travel (front)

    300 mm

  • Suspension travel (rear)

    300 mm

  • Front brake

    Disc brake

  • Rear brake

    Disc brake

  • Front brake disc diameter

    260 mm

  • Rear brake disc diameter

    220 mm

  • Chain

    5/8 x 1/4"

  • Steering head angle

    63.9 °

  • Wheelbase

    1485 ± 10 mm

  • Ground clearance

    370 mm

  • Seat height

    960 mm

  • Tank capacity (approx.)

    7 l

  • Weight READY TO RACE (without fuel)

    100.4 kg

[/vehicle]
[vehicle source="ktm" img="https://www.chapmoto.com/wp/wp-content/uploads/2015/12/2016-KTM-250-SX-F-Factory-Edition.jpg" url="http://www.ktm.com/us/mx/250-sx-f-factory-edition-2016/"]

Year|2016$Manufacturer|KTM$Model Name|250 SX-F Factory Edition$

Engine

  • Design

    1-cylinder, 4-stroke engine

  • Displacement

    249.9 cm³

  • Bore

    78 mm

  • Stroke

    52.3 mm

  • Starter

    Electric starter

  • Transmission

    5-speed

  • Primary drive

    24:73

  • Secondary gear ratio

    13:50

  • Clutch

    Wet, CSS multi-disc clutch, Brembo hydraulics

  • EMS

    Keihin EMS

Chassis

  • Frame design

    25CrMo4 steel central-tube frame

  • Front suspension

    WP-USD, AER 48, Ø 48 mm

  • Rear suspension

    WP shock absorber with linkage

  • Suspension travel (front)

    300 mm

  • Suspension travel (rear)

    300 mm

  • Front brake

    Disc brake

  • Rear brake

    Disc brake

  • Front brake disc diameter

    260 mm

  • Rear brake disc diameter

    220 mm

  • Chain

    5/8 x 1/4"

  • Steering head angle

    63.9 °

  • Wheelbase

    1485 mm

  • Ground clearance

    370 mm

  • Seat height

    960 mm

  • Tank capacity (approx.)

    7 l

  • Weight READY TO RACE (without fuel)

    98.5 kg

[/vehicle]
